X510-9
173
Miscellaneous Small Parts- Use with All Applications
(1) Contact Vehicle Manufacturer
(4) Includes Pressure Spring
Bills of Material Description & Item Number (Refer to
"Exploded View" at the front of this section) 603192 603193 603326 603327 603453
Seal & Guide Tube 31 — — 36352 36352 36352
Seal — 32542-1 32542-1 — — —
Guide — 30703 30703 — — —
Stop Screw 39 31026-1 31026-1 31026-1 31026-1 31026-1
Jam Nut 40 500381-3 500381-3 500381-3 500381-3 500381-3
Oil Seal 47 — — 34783 34783 34783
Spacer - Wheel Bearing Spindle 48 — — 35986 35986 35986
Oil Seal - Block Vee 49 — — — — —
Needle Bearing Assembly 50 30339 30339 550759 550759 550759
Nut - Brake Mounting 52 30688 30688 — (1) — (1) — (1)
Oil Seal 53 — (1) — — 34611 — (1)
Wheel Hub 55 — (1) — — — (1) — (1)
Lockwasher-Wheel Bearing 57 — — — — 17015
Nut-Wheel Bearing 58 30350 — — 30350 17016
Lockwasher-Wheel Bearing Nut 59 30343 — — 30343 17017
Gasket-Drive Flange 60 30344 — — 30344 18188
Flange-Axle Drive 61 30340 — — 30340 36436
Snap Ring 62 31624 31624 31624 31624 18270
Hub Cap 63 32001 — — 32001 32001
Nut 64 — (1) — — — (1) — (1)
Lockwasher 65 — (1) — — — (1) 501209-3
Stud 66 — (1) — — — (1) —
Hub Cap 67 — 31152 31152 — —
Axle Drive Gear 68 — 31125 31125 — —
Pressure Spring 69 — 35218 35218 — —
Plate-Spring Retaining 70 — 32589 32589 — —
Wheel Bearing Adjusting Nut 71 — 31139 31139 — —
Retaining Lock Nut 72 — 36569 36569 — —
Nut & Pin Assembly-Inner Lock 73 — 21588X 21588X — —
Wheel Hub 75 — — (1) — (1) — —
Oil Seal 77 — 34611 34611 — —
Hub Lock Assembly N.I. 27369-3X 26133-3X 26133-3X 27369-3X —
IHC Model 44 Front Axles
