Spicer Front and Rear Axle Catalog - Manual (Page 222)

X510-9
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
216
Bill of Material Table
Drive Pinion & Gear Assembly
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Inner Pinion Shims
5 Baffle – Pinion Bearing
6 Outer Pinion Shims
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
Differential Case Assembly (standard)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Case Assembly (Powr-Lok)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
23 Bolt – Drive Gear
38 Flange Half – Differential Case
39 Cap Half – Differential Case
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
48 Bolt – Differential Case
Differential Case (standard)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
29 Lock – Differential Shaft
Differential Case (Powr-Lok)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
38 Flange Half – Differential Case
39 Cap Half – Differential Case
48 Bolt – Differential Case
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
Differential Parts (standard)
15 Carrier Cover Gasket / Sealant
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Parts (Powr-Lok)
15 Carrier Cover Gasket / Sealant
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
1967-68 C-101 Jeepster
602883-1 Standard 3.31 706000-1X 25821X 706007X 706010X N.L.A. N.L.A.
602883-2 Powr-Lok 3.31 706000-1X 24825X 706005X 706009X N.L.A. N.L.A.
602883-3 Standard 3.73 706000-3X 23772X 706008X 706010X N.L.A. N.L.A.
602883-4 Powr-Lok 3.73 706000-3X 25362X 706006X 706009X N.L.A. N.L.A.
602883-5 Standard 4.27 706000-8X 23772X 706008X 706010X N.L.A. N.L.A.
602883-6 Powr-Lok 4.27 706000-8X 25362X 706006X 706009X N.L.A. N.L.A.
602883-7 Standard 4.88 706000-6X 23772X 706008X 706010X N.L.A. N.L.A.
602883-8 Powr-Lok 4.88 706000-6X 25362X 706006X 706009X N.L.A. N.L.A.
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
N.L.A. - Tapered Axle Shafts No Longer Available
AMC/Jeep Model 30 Rear Axles
Kit Components
