Spicer Front and Rear Axle Catalog - Manual (Page 57)

X510-9
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
(9) Use Internal Parts from Case Assembly
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
51
Bill of Material Table
1969-70 F-100 & F-150 1/2 Ton Pick-up (Part Time Transfer Case) (Continued)
603128-8 Standard 3.54 706617-13X 706614X 706615X 706616X 902811-1 902811-2
603128-9 Standard 4.09 706617-15X 706695X 706696X 706616X 902811-1 902811-2
603128-10 Power-Lok 4.09 706617-15X 23715X 23436X 23714X 902811-1 902811-2
603128-11 Standard 3.54 706617-13X 706614X 706615X 706616X 902811-1 902811-2
1971 F-100 & F-150 1/2 Ton Pick-up (Part Time Transfer Case)
603289-1 Standard 3.54 706617-13X 706614X 706615X 706616X 902811-1 902811-2
603289-2 Standard 3.54 706617-13X 706614X 706615X 706616X 902811-1 902811-2
603289-3 Standard 3.73 706617-14X 706614X 706615X 706616X 902811-1 902811-2
603289-4 Standard 3.73 706617-14X 706614X 706615X 706616X 902811-1 902811-2
603289-5 Standard 4.09 706617-15X 706695X 706696X 706616X 902811-1 902811-2
603289-6 Standard 4.09 706617-15X 706695X 706696X 706616X 902811-1 902811-2
603289-7 Trac-Lok 3.54 706617-13X 706628X 706629X 706630X 902811-1 902811-2
603289-8 Trac-Lok 4.09 706617-15X 706658X 706659X 706630X 902811-1 902811-2
603289-9 Standard 4.09 706617-15X 706695X 706696X 706616X 902811-1 902811-2
603289-10 Standard 4.09 706617-15X 706695X 706696X 706616X 902811-1 902811-2
603289-11 Standard 3.54 706617-13X 706614X 706615X 706616X 902811-1 902811-2
603289-12 Standard 3.54 706617-13X 706614X 706615X 706616X 902811-1 902811-2
1972 F-100 & F-150 1/2 Ton Pick-up (Part Time Transfer Case)
603303-1 Standard 3.54 706617-13X 706614X 706615X 706616X 904686-5 904686-6
603303-2 Standard 3.54 706617-13X 706614X 706615X 706616X 904686-5 904686-6
603303-3 Standard 3.73 706617-14X 706614X 706615X 706616X 904686-5 904686-6
603303-4 Standard 3.73 706617-14X 706614X 706615X 706616X 904686-5 904686-6
603303-5 Standard 4.09 706617-15X 706695X 706696X 706616X 904686-5 904686-6
603303-6 Standard 4.09 706617-15X 706695X 706696X 706616X 904686-5 904686-6
603303-7 Trac-Lok 4.09 706617-15X 706658X 706659X 706630X 904686-5 904686-6
603303-8 Trac-Lok 3.54 706617-13X 706628X 706629X 706630X 904686-5 904686-6
1973 F-100 & F-150 1/2 Ton Pick-up (Part Time Transfer Case)
603394-1 Standard 3.54 706617-13X 706614X 706615X 706616X 660003-1 660003-2
603394-2 Standard 3.54 706617-13X 706614X 706615X 706616X 660003-1 660003-2
603394-3 Standard 3.73 706617-14X 706614X 706615X 706616X 660003-1 660003-2
603394-4 Standard 3.73 706617-14X 706614X 706615X 706616X 660003-1 660003-2
603394-5 Standard 4.09 706617-15X 706695X 706696X 706616X 660003-1 660003-2
603394-6 Standard 4.09 706617-15X 706695X 706696X 706616X 660003-1 660003-2
603394-7 Trac-Lok 3.54 706617-13X 706628X 706629X 706630X 660003-1 660003-2
603394-8 Standard 3.54 706617-13X 706614X 706615X 706616X 660003-1 660003-2
603394-9 Standard 4.09 706617-15X 706695X 706696X 706616X 660003-1 660003-2
603394-10 Trac-Lok 4.09 706617-15X 706658X 706659X 706630X 660003-1 660003-2
1974-75 F-100 & F-150 1/2 Ton Pick-up (Part Time Transfer Case)
603472-1 Standard 3.54 706617-13X 706614X 706615X 706616X 660003-1 660003-2
603472-2 Standard 3.54 706617-13X 706614X 706615X 706616X 660003-1 660003-2
603472-3 Standard 3.73 706617-14X 706614X 706615X 706616X 660003-1 660003-2
603472-4 Standard 3.73 706617-14X 706614X 706615X 706616X 660003-1 660003-2
603472-5 Standard 4.09 706617-15X 706695X 706696X 706616X 660003-1 660003-2
603472-6 Standard 4.09 706617-15X 706695X 706696X 706616X 660003-1 660003-2
603472-7 Trac-Lok 3.54 706617-13X 706628X 706629X 706630X 660003-1 660003-2
603472-8 Standard 3.54 706617-13X 706614X 706615X 706616X 660003-1 660003-2
603472-9 Standard 3.50 706617-17X 706614X 706615X 706616X 660003-1 660003-2
Continued on next page
Ford Model 44 Front Axles
