75
X510-9
ITEM DESCRIPTION
NO.
Kit Components
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
Drive Pinion & Gear Assembly
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Inner Pinion Shims
5 Baffle – Pinion Bearing
6 Outer Pinion Shims
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
Differential Case Assembly (standard)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Case Assembly (Powr-Lok)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
23 Bolt – Drive Gear
38 Flange Half – Differential Case
39 Cap Half – Differential Case
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
48 Bolt – Differential Case
Differential Case Assembly (Trac-Lok)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
49 Case – Differential
50 Gear – Differential
51 Shaft – Differential
52 Snap Ring
53 Spacer – Diff. Gear (dished)
54 Plate – Differential
55 Disc – Differential
56 Plate – Differential (dished)
57 Clip – Differential Clutch Retainer
Differential Case (standard)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
29 Lock – Differential Shaft
Differential Case (Powr-Lok)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
38 Flange Half – Differential Case
39 Cap Half – Differential Case
48 Bolt – Differential Case
Differential Case (Trak-Lok)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
48 Bolt – Differential Case
49 Differential Case
52 Snap Ring
Differential Parts (standard)
15 Carrier Cover Gasket / Sealant
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Parts (Powr-Lok)
15 Carrier Cover Gasket / Sealant
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
Differential Parts (Trac-Lok)
15 Carrier Cover Gasket / Sealant
23 Bolt – Drive Gear
24 Pinion – Differential
26 Thrustwasher – Diff. Pinion
50 Gear – Differential
51 Shaft – Differential
52 Snap Ring
53 Spacer – Diff. Gear (dished)
54 Plate – Differential
55 Disc – Differential
56 Plate – Differential (dished)
57 Clip – Differential Clutch Retainer
Ford Model 44 Rear Axles
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
