151
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
X510-9
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
GMC / Chevrolet Model 70 Rear Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Shim – Drive Pinion
5 Baffle – Pinion Bearing
6 Shim – Pinion Bearing
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
10 (2) End Yoke Assembly
11 Washer – Pinion Nut
12 Pinion Nut
13 (2) Companion Flange Assembly
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
18 (2) Differential Bearing Cap
19 (2) Bolt – Differential Bearing Cap
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Differential Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
30 Brake Mounting Bolt
31 Brake Mounting Nut
32 Hub Seal
33 KIT – Inner Wheel Bearing
34 KIT – Outer Wheel Bearing
35 Wheel Hub
36 Spindle Nut – Inner
37 Lockwasher – Spindle Nut
38 Spindle Nut – Outer
39 Shaft – Axle Flanged Drive
40 Spacer – Differential Bearing
Power-Lok & Trak-Lok
Differential
41 Flange Half - Differential Case
42 Cap Half – Differential Case
43 Shaft – Differential
44 Pinion – Differential
45 Gear – Differential
46 Ring – Differential
47 Plate – Differential
48 Disc – Differential
49 Disc – Differential (dished)
50 Plate – Differential (dished)
51 Bolt – Differential Case
For C20/25, C30, C300,
G300 Models
Axle B.M. 603354, 603476,
603537, 603703, 603704
For G300 Models
Axle B.M. 603546
For P300 Models
Axle B.M. 603408, 603474,
603536, 603657, 603753,
603881
30175 30137 — (2) 706179X 706074X — (2) 33733 33732
30175 30137 — (2) 706073X 706074X — (2) 33733 33732
36638 — (2) — (2) — (2) — (2) 36636 36635
(1) Not a Kit (1 each required for all applications listed)
(2) Contact Vehicle Manufacturer for Service
Inner Outer Spindle Spindle
H u b Wheel Wheel Wheel Nut/ Nut Spindle
VEHICLE MODEL &
Bolt Nut Seal Bearing Bearing H u b Washer Lock Nut
BILL OF MATERIAL BASE NUMBER
Kit Kit Inner Washer Outer
(item 30) (item 31) (item 32) (item 33) (item 34) (item 35) (item 36) (item 37) (item 38)
BRAKE MOUNTING
(1)
33732
33734
(1)
33732
33734
(1)
36635
36637
(1)
36640
500357-14
Miscellaneous Small Parts - Use with All Applications
