209
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
X510-9
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
AMC/Jeep Model 30 Front Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 Slinger – Inner Pinion Bearing
4 KIT – Inner Pinion Bearing
5 Inner Pinion Shims
6 Baffle – Pinion Bearing
7 Outer Pinion Shims
8 KIT – Outer Pinion Bearing
9 Slinger – Outer Pinion Bearing
10 Seal – Pinion Oil
11 (2) End Yoke Assembly
12 Washer – Pinion Nut
13 Pinion Nut
14 (2) Companion Flange Assembly
15 Carrier Cover
16 Carrier Cover Gasket / Sealant
17 Plug – Carrier Cover
18 Bolt – Carrier Cover
19 (1) Differential Bearing Cap
20 (1) Bolt – Differential Bearing Cap
21 KIT – Differential Bearing
22 Shim – Differential Bearing
23 Case – Differential
24 Bolt – Drive Gear
25 Pinion – Differential
26 Gear – Differential
27 Thrustwasher – Diff. Pinion
28 Thrustwasher – Diff. Gear
29 Shaft – Differential Pinion
30 Lock – Differential Shaft
31 (1) Seal & Guide Tube
32 Nut - Hex Slotted
33 Cotter Pin
34 Adjusting Split RIng
35 Upper Socket Assembly
36 Lock Nut
37 Lower Socket Assembly
38 Snap Ring
39 Stop Screw
40 Jam Nut
41 Knuckle Assembly
42 (1) Nut - Hex Slotted
43 (1) Cotter Pin
44 (1) Tie Rod Assembly
45 Shaft & Joint Assembly
46 Slinger – Spindle Yoke
(pressed on axle shaft if used)
47 Oil Seal
48 Spacer – Wheel Bearing Spindle
48A Oil Seal - Block Vee
49 Needle Bearing Assembly
50 Wheel Bearing Spindle
51 Brake Mounting Nut
52 Oil Seal
53 KIT – Inner Wheel Bearing
54 (1) Wheel Hub
55 KIT – Outer Wheel Bearing
56 Lockwasher – Wheel Bearing
57 Nut – Wheel Bearing
58 Lockwasher – Wheel Bearing Nut
59 Drive Flange Gasket
60 Axle Drive Flange
61 Snap Ring
62 Hub Cap
63 Lockwasher
64 Nut
65 Stud
Power-Lok & Trak-Lok
Differential
66 Flange Half – Differential Case
67 Cap Half – Differential Case
68 Shaft – Differential
69 Pinion – Differential
70 Gear – Differential
71 Ring – Differential Gear
72 Plate – Differential
73 Disc – Differential
74 Disc – Differential (dished)
75 Plate – Differential (dished)
76 Bolt – Differential Case
