X510-9
81
Kits & Parts — Use with All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
603448 603628 603765 603786 603799
Inner Pinion Bearing Kit 4 706046X 706046X 706046X 706046X 706046X
Pinion & Bearing Adjusting Shim 706672X 706672X 706672X 706672X 706359X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim 706674X 706674X 706674X 706674X 706375X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing 8 706045X 706045X 706045X 706045X 706045X
Carrier Cover (inc. 15, 16, 17, 18) 706128X 706407X 706128X 706128X 706044X
Differential Bearing Adj. Shim (16, 22) 706673X 706673X 706673X 706673X 706374X
Differential Bearing 21 706047X 706047X 706047X 706047X 706047X
Seal & Guide Tube 31 36913 36913 36913 36913 36913
Seal — Upper King Pin 32 — — 620058 620058 37303
KIT — King Pin Parts (inc. 32,33,34,35) N.I. — — 706395X 706395X 706395X
KIT — King Pin Bearing 35 706150X 706150X 706150X 706150X 706150X
Steering Knuckle Assembly - RH N.I. 706364X 706364X — — —
(inc. items 35, 49, 50, 51, 52)
Steering Knuckle Assembly - LH N.I. 706365X 706365X — — —
(inc. items 35, 49, 50, 51, 52)
Stop Screw 36 30902 30902 31026-3 31026-3 31026-3
Jam Nut 37 500381-3 500381-3 500381-3 500381-3 500381-3
Cotter Pin 39 500024-4 500024-4 500024-4 500024-4 500024-4
Lube Fitting 40 — — 500175-4 500175-4 500175-4
Nut — Hex Tapered 41 30875 30875 30875 30875 30875
KIT — Knuckle Oil Seal & Bolt N.I. 706230X 706230X — — —
KIT — Steering Arm (inc. 41, 42, 43) N.I. 706153X 706153X — — —
Steering Arm (LH only) 43 25439X 25439X 38086 38086 38086
Cap — Upper King Pin (RH only) 35183 35183 620132 620132 620132
Gasket — King Pin Cap 44 — — 37307 37307 37307
Compression Spring 45 — — 37300 37300 37300
Retainer Spring 46 — — — — —
Bushing — King Pin 47 — — 37301 37301 37301
Knuckle Assembly (RH only) 49 29093X 29093X 29523X 29523X 29523X
Knuckle Assembly (LH only) N.I. 29094X 29094X 29524X 29524X 29524X
Cap — Lower King Pin (RH only) 50 35183 35183 37299 37299 37299
Lockwasher — Lower King Pin Cap 51 500357-1 500357-1 500357-1 500357-1 500357-13
Hex Bolt — Lower King Pin Cap 52 500412-1 500412-1 500412-1 500412-1 500412-12
KIT — Wheel Spindle Seal & Bearing N.I. 28443X — 706109X 706527X 706527X
(inc. items 55, 56, 57, 58)
KIT — Wheel Bearing Spindle N.I. — — 706553X 706553X 706553X
(inc. items 57, 58, 59)
Nut — Brake Mounting 60 36954 36954 36805 36805 36805
Washer — Brake Mounting N.I. 36953 36953 — — —
Oil Seal 61 35311 35311 35311 35311 35311
Inner Wheel Bearing 62 706139X 706139X 706139X 706139X 706139X
Outer Wheel Bearing 64 706111X 706111X 706111X 706111X 706111X
Nut — Wheel Bearing Inner 65 21588X 21588X 21588X 21588X 21588X
Retaining Lock Nut 66 36569 36569 36569 36569 31139
Nut — Wheel Bearing Outer 67 31139 31139 31139 31139 —
Flange - Axle Drive 68 30340 30340 30340 30340 30340
Gasket - Drive Flange N.I. 30344 30344 30344 30344 —
Snap Ring 69 31624 31624 31624 31624 31624
Stud 70 31017 31017 31017 31017 31017
Nut N.I. 500371-3 500371-3 500371-3 500371-3 500371-3
Washer N.I. 501209-3 501209-3 501209-3 501209-3 501209-3
Hub Cap 71 32001 32001 32001 32001 32001
Wheel Bearing Adjusting Nut - Inner 81 — — — — —
Ford Model 60 Front Axles
