X510-9
125
Miscellaneous Small Parts- Use with All Applications
Bills of Material Description & Item Number (Refer to
"Exploded View" at the front of this section) 603349 603374 603375 603454 603675
603352 603455 603706
Seal & Guide Tube 31 36352 36352 36352 36352 36352
Seal — — — — — —
Guide — — — — — —
Stop Screw 39 31026-1 31026-1 31026-1 31026-1 31026-1
Jam Nut 40 500381-3 500381-3 500381-3 500381-3 500381-3
Oil Seal 47 34783 38128 38128 38128 38128
Spacer - Wheel Bearing Spindle 48 35986 38106 38106 38106 38106
Oil Seal - Block Vee 49 — — 36361 36361 36361
Needle Bearing Assembly 50 550759 550759 550759 550759 550759
Nut - Brake Mounting 52 — (3) 35704 35704 35704 35704
Oil Seal 53 36369 — 36369 — —
Wheel Hub 55 — (3) — — (3) — —
Gasket-Drive Flange 60 30344 — 30344 — —
Flange-Axle Drive 61 30340 — 30340 — —
Snap Ring 62 31624 31624 31624 31624 31624
Hub Cap 63 32001 — 32001 — —
Nut 64 500371-3 — 500371-3 500371-3 —
Lockwasher 65 501209-3 — 501209-3 501209-3 —
Stud 66 31017 — 31017 31017 —
Hub Cap 67 — 36858 — 36858 36858
Axle Drive Gear 68 — 31125 — 31125 31125
Pressure Spring 69 — 35218 — 35218 35218
Plate-Spring Retaining 70 — 32589 — 32589 32589
Wheel Bearing Adjusting Nut 71 31139 31139 31139 31139 31139
Retaining Lock Nut 72 36569 36569 36569 36569 36569
Nut & Pin Assembly-Inner Lock 73 21588X 21588X 21588X 21588X 21588X
Wheel Hub 75 — — (3) — — (3) — (3)
Oil Seal 77 — 36366 — 36366 36366
Hub Lock Assembly N.I. 27369-3X 26133-3X 27369-3X 26133-3X 26133-3X
GMC / Chevrolet Model 44 Front Axles
(3) Contact Vehicle Manufacturer
