X510-9
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
153
Bill of Material Table
1977 P-300 Motor Home - 1 Piece Case
603657-4 Standard 4.56 706048-3X 706065X 706069X 706058X 36625-1 36625-1
603657-5 Standard 4.88 706048-4X 706065X 706069X 706058X 36625-1 36625-1
1978 P-300 Motor Home - 1 Piece Case
603881-1 Standard 4.56 706048-3X 706065X 706069X 706058X 36625-1 36625-1
603881-2 Standard 4.88 706048-4X 706065X 706069X 706058X 36625-1 36625-1
36453-1 1 1 /
2
" -35 1 5 /
8
" 40 1 /
16
" 4 3 /
4
" 3 31 /
32
" 8
36625-1 1 1 /
2
" -35 1 5 /
8
" 36 11 /
16
" 3 25 /
32
" (20T Splined End)
Axle Shaft Dimensions
Spline Bolts
Part
Number
Diameter &
Number of
Splines
Length Flange Face
to End of
Spline
Flange
Diameter
Circle
Diameter
Number of
Bolt Holes
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
(9) On Model G-300 Bills of Material 603546 and 603703 use Kit Number 706047X
(10) On Model G-300 Bills of Material 603546 and 603703 use Kit Number 706378X
(11) On Model C-300 Bills of Material 6035471 and 603704 use Kit Number 706077X
Common Axle Kits - Use with All Applications
ITEM DESCRIPTION KIT PART
NO. NUMBER
ITEM DESCRIPTION KIT PART
NO. NUMBER
Inner Pinion Bearing 706060X
3 KIT – Inner Pinion Bearing
Outer Pinion Bearing 706045X
7 KIT – Outer Pinion Bearing
Carrier Cover Kit
Axle B.M. 603354, 603408, 603474, 603476,
706100X
603536, 603537
Axle B.M. 603546, 603703 706149X
Axle B.M. 603704, 603753, 603657, 603881 706058X
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
Differential Bearing 706070X (9)
20 KIT – Differential Bearing
Pinion & Bearing Adjusting Shim 706357X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
Differential Bearing Adjusting Shim 706373X (10)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
Differential & Pinion Shim 706213X (11)
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
GMC / Chevrolet Model 70 Rear Axles
