Spicer Front and Rear Axle Catalog - Manual (Page 201)

195
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
X510-9
ITEM DESCRIPTION
NO.
Kit Components
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
Carrier Cover
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
Drive Pinion & Gear Assembly
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Inner Pinion Shims
5 Baffle – Pinion Bearing
6 Outer Pinion Shims
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
Differential Case Assembly (standard)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Case Assembly (Powr-Lok)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
23 Bolt – Drive Gear
51 Flange Half – Differential Case
52 Cap Half – Differential Case
53 Shaft – Differential
54 Pinion – Differential
55 Gear – Differential
56 Ring – Differential Gear
57 Plate – Differential
58 Disc – Differential
59 Disc – Differential (dished)
60 Plate – Differential (dished)
61 Bolt – Differential Case
Differential Case Assembly (Trac-Lok)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
23 Bolt – Drive Gear
24 Pinion – Differential
26 Thrustwasher – Diff. Pinion
28 Shaft – Differential
29 Lock – Differential Shaft
44 Case – Differential
45 Gear – Differential
46 Spacer – Diff. Gear (dished)
47 Plate – Differential
48 Disc – Differential
49 Plate – Differential
50 Clip – Diff. Clutch Retainer
Differential Case (standard)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
29 Lock – Differential Shaft
Differential Case (Powr-Lok)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
51 Flange Half – Differential Case
52 Cap Half – Differential Case
61 Bolt – Differential Case
Differential Case (Trac-Lok)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
29 Lock – Differential Shaft
44 Case – Differential
Differential Parts (standard)
15 Carrier Cover Gasket / Sealant
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Parts (Powr-Lok)
15 Carrier Cover Gasket / Sealant
53 Shaft – Differential
54 Pinion – Differential
55 Gear – Differential
56 Ring – Differential Gear
57 Plate – Differential
58 Disc – Differential
59 Disc – Differential (dished)
60 Plate – Differential (dished)
Differential Parts (Trac-Lok)
15 Carrier Cover Gasket / Sealant
23 Bolt – Drive Gear
24 Pinion – Differential
26 Thrustwasher – Diff. Pinion
28 Shaft – Differential
29 Lock – Differential Shaft
45 Gear – Differential
46 Spacer – Diff. Gear (dished)
47 Plate – Differential
48 Disc – Differential
49 Plate – Differential
50 Clip – Diff. Clutch Retainer
IHC Model 60 Rear Axles
