X510-9
66
Miscellaneous Small Parts
(3) Contact Vehicle Manufacturer
Bills of Material Description & Item Number (Refer to
"Exploded View" at the front of this section) 603690 603762 603780 603781 603782
Inner Pinion Bearing Kit 4 706031X 706031X 706031X 706031X 706031X
Pinion & Bearing Adjusting Shim 706617X 706617X 706358X 706358X 706358X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim 706619X 706619X 706376X 706376X 706376X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing 8 706030X 706030X 706030X 706030X 706030X
Carrier Cover (inc. 15, 16, 17, 18) 700038 706154X 706112X 700038 700038
Differential Bearing Adj. Shim (16, 22) 706618X 706618X 706086X 706086X 706086X
Differential Bearing 21 706032X 706032X 706032X 706032X 706032X
Seal & Guide Tube 31 36352 36352 36352 36352 36352
Seal — — — — —
Guide — — — — —
Steering Knuckle Assembly - RH 706491X 706493X 706488X 706491X 706491X
(inc. items 32, 33, 34, 36, 41)
Steering Knuckle Assembly - LH N.I. 706492X 706494X 706489X 706492X 706492X
Socket Assy (32,33,34,35,36,37,38) 706116X 706116X 706116X 706116X 706116X
Steering Arm N.I. — 706235X — — —
Wheel Spindle Seal & Bearing 706527X 706527X 706527X 706527X 706527X
(inc. items 47, 48, 49, 50)
Wheel Bearing Spindle 706552X 706553X 706552X 706552X 706552X
(inc. items 47, 48, 49, 50, 51 or 74)
Stop Screw 39 31026-2 31026-2 31026-2 31026-2 31026-2
Jam Nut 40 500381-3 500381-3 500381-3 500381-3 500381-3
Oil Seal 47 38128 38128 38128 38128 38128
Spacer - Wheel Bearing Spindle 48 38106 38106 38106 38106 38106
Oil Seal - Block Vee 49 36361 36361 36361 36361 36361
Needle Bearing Assembly 50 550759 550759 550759 550759 550759
Nut - Brake Mounting 52 36805 36805 36805 36805 36805
Oil Seal 53 35311 35311 — — —
Inner Wheel Bearing 54/76 706110X 706110X 706110X 706110X 706110X
Cup — — — — —
Cone — — — — —
Wheel Hub 55 — (3) — (3) — — —
Outer Wheel Bearing 56/74 706111X 706111X 706111X 706111X 706111X
Gasket-Drive Flange 60 — 30344 — — —
Flange-Axle Drive 61 — 30340 — — —
Snap RIng 62 31624 31624 31624 31624 31624
External Hub Cap 63 — 32001 31552 31552 31552
Nut 64 — 500371-3 — — —
Lockwasher 65 — 501209-3 — — —
Stud 66 — 31017 — — —
Internal Hub Cap 67 31552 — 31552 31552 31552
Axle Drive Gear 68 31125 — 31125 31125 31125
Pressure Spring 69 35218 — 35218 35218 35218
Plate-Spring Retaining 70 32589 — 32589 32589 32589
Wheel Bearing Adjusting Nut 71 31139 31139 31139 31139 31139
Retaining Lock Nut 72 36569 36569 36569 36569 36569
Nut & Pin Assembly-Inner Lock 73 21588X 21588X 21588X 21588X 21588X
Wheel Hub 75 — (3) — (3) — (3) — (3) — (3)
Oil Seal 77 35313 35313 35313
Hub Lock Assembly N.I. 26133X 27369-2X 26133-3X 26133-3X —
Knuckle Oil Seal & Bolt N.I. — — — — —
King Pin Bearing N.I. — — — — —
Ford Model 44 Front Axles
