X510-8
246
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
Common Axle Kits - Use with All Applications
ITEM DESCRIPTION KIT PART
NO. NUMBER
ITEM DESCRIPTION KIT PART
NO. NUMBER
Inner Pinion Bearing 706046X
3 KIT – Inner Pinion Bearing
Outer Pinion Bearing 706045X
7 KIT – Outer Pinion Bearing
Outer Pinion Bearing 706047X
20 KIT – Differential Bearing
Pinion & Bearing Adjusting Shim 706672X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
Differential Bearing Adjusting Shim 706673X
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
Differential & Pinion Shim 706674X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
AMC/Jeep Model 60 Rear Axles
For J20 Model
Axle B.M. 603137 34616-1 35704 35512 35961 565904 35511 35510
Full-Float Design
Semi-Float Design
(3) Contact Vehicle Manufacturer for Service
Miscellaneous Small Parts - Use With All Applications
VEHICLE MODEL & H u b Spindle Spindle
BILL OF MATERIAL Bolt Nut Seal C u p Cone C u p Cone Nut Lockwasher
BASE NUMBER (item 30) (item 31) (item 32) (item 33) (item 34) (item 36) (item 37)
Brake Mounting Inner Wheel Bearing Outer Wheel Bearing
For J20 Model
Axle B.M. 603125 Contact Vehicle Manufacturer for Service
Axle B.M. 603470 500411-10 36805 35697 (3) 550189 (3) 550390 30636 30637
For Post Office Van
Axle B.M. 603803
500411-10 36805 35697 550232 550189 550369 550390 30636 30637
VEHICLE MODEL & Inboard Wheel Bearing Wheel Bearing Outboard Oil Seal
BILL OF MATERIAL Bolt Nut Shaft Seal Retaining Ring Assembly Shaft Seal Retainer
BASE NUMBER (item 30) (item 31) (item 39) (item 40) (item 41) (item 42) (item 43)
Brake Mounting
