Spicer Front and Rear Axle Catalog - Manual (Page 22)

16
Axle Kits & Parts - Use with All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
X510-8
603500 603643
KIT – Inner Pinion Bearing 4 706046X 706046X
PKG – Pinion & Bearing Shim — 706672X 706672X
(inc. items 5, 7, 12, 13, 16)
PKG – Differential & Pinion Shim — 706674X 706674X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing 8 706045X 706045X
Carrier Cover (inc. 15, 16, 17, 18) — 706078X 706078X
PKG – Diff. Bearing Shim (16 & 22) — 706673X 706673X
Differential Bearing 21 706047X 706047X
Seal & Guide Tube 31 36487 36487
Seal – Upper King Pin 32 620058 620058
KIT – King Pin Parts (inc 33, 34, 35) N.I. 706395X 706395X
Stop Screw 36 31026-3 31026-1
Jam Nut 37 500381-3 500381-3
Cotter Pin 39 500024-5 500024-5
Lube Fitting 40 500175-4 500175-4
Nut – Hex Tapered 41 30875 30875
Steering Arm (LH only) 43 38521 38521
Upper King Pin Cap (RH only) 620132 620132
Gasket – King Pin Cap 44 37307 37307
Compression Spring 45 37300 37300
Retainer Spring 46 — 620180
King Pin Bushing 47 37301 37301
King PIn 48 37302 37302
Knuckle Assembly (RH only) 49 28792X 28792X
Knuckle Assembly (LH only) N.I. 28793X 28793X
Lower King Pin Bearing Cap 50 37299 37299
Lockwasher – Lower King Pin Cap 51 500357-13 500357-13
Hex Bolt – Lower King Pin Cap 52 500412-12 500412-12
KIT – Wheel Spindle Seal & Bearing N.I. 700014 700014
(inc. items 56, 57, 58, 59)
KIT – Wheel Bearing Spindle (58,59,60) N.I. 700013 700013
Brake Mounting Nut 60 36880 36880
Brake Mounting Washer N.I. — 38081-1
Oil Seal 61 37729 37729
KIT – Inner Wheel Bearing 62 706411X 706411X
KIT – Outer Wheel Bearing 64 706074X 706074X
Inner Wheel Bearing Nut 65 35270 35270
Lock Nut 66 35269 35269
Outer Wheel Bearing Nut 67 35270 35270
Axle Drive Flange Gasket 68 37313 37313
Snap Ring 69 37730 37730
Bolt 70 37734 37734
Hub Cap 71 32001 32001
N.I. - Not Illustrated
RH - Right Hand
LH - Left Hand
Axle Shaft Dimensions
Inner Shaft - Side Gear End Outer Shaft - Spline End Axle Shaft & Joint Assembly
Complete
Assembly
Number
Major
Spline
Diameter
Centerline
to End of
Spline
Yoke Shaft
Part
Number
Major
Spline
Diameter
Centerline
to End of
Spline
Yoke Shaft
Part
Number
Side
Overall
Length
Cross &
Bearing Kit
907967-5 1 1 /
2
" -35 17 43 /
64
" 3-82-801-5 1 5 /
16
" -30 12" 3-82-791 Right 29 43 /
64
" 5-332X
907967-6 1 1 /
2
" -35 35 5 /
64
" 3-82-801-6 1 5 /
16
" -30 12" 3-82-791 Left 47 5 /
64
" 5-332X
Dodge Model 60 Front Axles
