Spicer Front and Rear Axle Catalog - Manual (Page 138)

X510-9
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
136
Bill of Material Table
1967-68 C10, I1000 1/2 Ton Pick-up & Station Wagon on Truck Chassis
602925-13 Standard 3.07 706613-2X 706614X 706615X 706616X N.L.A. N.L.A.
602925-14 Power-Lok 3.07 706613-2X 23686X 23435X — (9) N.L.A. N.L.A.
602925-15 Standard 3.54 706613-4X 706614X 706615X 706616X N.L.A. N.L.A.
602925-16 Power-Lok 3.54 706613-3X 23686X 23435X — (9) N.L.A. N.L.A.
602925-17 Standard 3.92 706613-14X 706695X 706696X 706616X N.L.A. N.L.A.
602925-18 Power-Lok 3.92 706613-14X 23687X 23436X — (9) N.L.A. N.L.A.
602925-20 Standard 3.73 706613-6X 706614X 706615X 706616X N.L.A. N.L.A.
602925-21 Power-Lok 3.73 706613-6X 23686X 23435X — (9) N.L.A. N.L.A.
602925-22 Standard 4.09 706613-5X 706695X 706696X 706616X N.L.A. N.L.A.
602925-23 Power-Lok 4.09 706613-5X 23687X 23436X — (9) N.L.A. N.L.A.
1968 C15 1/2 Ton Pick-up & Station Wagon on Truck Chassis
603039-1 Standard 3.07 706613-2X 26412X 35177 — (9) N.L.A. N.L.A.
603039-2 Power-Lok 3.07 706613-2X 26415X 26416X — (9) N.L.A. N.L.A.
603039-3 Standard 3.07 706613-2X 26412X 35177 — (9) N.L.A. N.L.A.
603039-4 Power-Lok 3.07 706613-2X 26415X 26416X — (9) N.L.A. N.L.A.
1968 K15 1/2 Ton Pick-up & Station Wagon on Truck Chassis
602988-1 Standard 3.54 706613-4X 706614X 706615X 706616X N.L.A. N.L.A.
602988-2 Power-Lok 3.54 706613-4X 23686X 23435X — (9) N.L.A. N.L.A.
GMC / Chevrolet Model 44 Rear Axles
N.L.A. - Tapered axle shafts No Longer Available
(7)
See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
(9) Use Internal Parts from Case Assembly
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
ITEM DESCRIPTION
NO.
Kit Components
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
Drive Pinion & Gear Assembly
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Inner Pinion Shims
5 Baffle – Pinion Bearing
6 Outer Pinion Shims
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
Differential Case Assembly (standard)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Case Assembly (Powr-Lok)
15 Carrier Cover Gasket / Sealant
20 KIT – Differential Bearing
21 Shim – Differential Bearing
23 Bolt – Drive Gear
38 Flange Half – Differential Case
39 Cap Half – Differential Case
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
48 Bolt – Differential Case
Differential Case (standard)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
29 Lock – Differential Shaft
Differential Case (Powr-Lok)
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
23 Bolt – Drive Gear
38 Flange Half – Differential Case
39 Cap Half – Differential Case
48 Bolt – Differential Case
Differential Parts (standard)
15 Carrier Cover Gasket / Sealant
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Diff. Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
Differential Parts (Powr-Lok)
15 Carrier Cover Gasket / Sealant
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
