Axle Kits & Small Parts - Use with All Applications
(3) Contact Vehicle Manufacturer
(4) For 1974 use Carrier Cover Kit 706192X
Description & Item Number (Refer to
"Exploded View" at the front of this section)
Bills of Material
603426
603451
603562
603730
Inner Pinion Bearing Kit
4
706015X
706015X
706015X
706015X
Pinion & Bearing Adjusting Shim
—
706360X
706360X
706360X
706360X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim
—
706386X
706386X
706386X
706377X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing
8
706014X
706014X
706014X
706030X
Carrier Cover (inc. 15, 16, 17, 18)
—
706090X
706090X
706090X
706090X
Differential Bearing Adj. Shim (16, 22)
—
706087X
706087X
706087X
706087X
Differential Bearing
21
706016X
706016X
706016X
706016X
Seal & Guide Tube
31
—
36410
36410
36410
Steering Knuckle Assembly - RH
—
706194X
28975X
706194X
706194X
(inc. items 32, 33, 34, 36, 41)
Steering Knuckle Assembly - LH
N.I.
706195X
28976X
706195X
706195X
Socket Assy (32,33,34,35,36,41)
—
706116X
706116X
706116X
706116X
Stop Screw
39
31026-1
31026-1
31026-1
31026-1
Jam Nut
40
500381-3
500381-3
500381-3
500381-3
Wheel Spindle Seal & Bearing
—
—
—
—
706527X
(inc. items 47, 48, 48A, 49)
Wheel Bearing Spindle
—
28382X
27817X
706171X
706533X
(inc. items 47, 48, 48A, 49, 50)
Oil Seal
47
36544
34783
38128
38128
Spacer - Wheel Bearing Spindle
48
—
35986
38106
38106
Oil Seal - Block Vee
48A
—
—
—
36361
Needle Bearing Assembly
49
—
550759
550759
550759
Nut - Brake Mounting
51
—
(1)
—
(1)
—
(1)
—
(1)
KIT — Inner Wheel Bearing
53
—
(1)
—
(1)
—
(1)
—
(1)
KIT — Outer Wheel Bearing
55
706111X
706111X
706111X
706111X
Gasket-Drive Flange
59
18188
18188
18188
18188
Flange-Axle Drive
60
—
36436
36436
36436
Snap Ring
61
—
18270
18270
18270
Hub Cap
62
—
(1)
32001
32001
32001
Lockwasher
64
501209-3
501209-3
501209-3
501209-3
Lockwasher-Wheel Bearing
84
17015
17015
17015
17015
Nut-Wheel Bearing
85
17016
17016
17016
17016
Lockwasher-Wheel Bearing Nut
86
17017
17017
17017
17017
Hub Lock Assembly
N.I.
—
—
—
—
IHC Model 30 Front Axles
