Spicer Front and Rear Axle Catalog - Manual (Page 200)

X510-9
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
194
Bill of Material Table
1973-75 1200 4 x 2 Vehicles (Continued)
603492-11 Standard 3.54 706660-1X 706664X 706668X 706671X 32987-3 32987-3
603492-12 Trac-Lok 3.54 706660-1X 706662X 706666X 706670X 32987-3 32987-3
1973-75 1200 4 x 4 Vehicles
603490-1 Standard 4.10 706660-3X 706664X 706668X 706671X 32987-3 32987-3
603490-2 Trac-Lok 4.10 706660-3X 706662X 706666X 706670X 32987-3 32987-3
603490-3 Standard 4.88 706660-5X 706665X 706669X 706671X 32987-3 32987-3
603490-4 Trac-Lok 4.88 706660-5X 706663X 706667X 706670X 32987-3 32987-3
603490-9 Standard 3.73 706660-2X 706664X 706668X 706671X 32987-3 32987-3
603490-10 Trac-Lok 3.73 706660-2X 706662X 706666X 706670X 32987-3 32987-3
603490-11 Standard 3.54 706660-1X 706664X 706668X 706671X 32987-3 32987-3
603490-12 Trac-Lok 3.54 706660-1X 706662X 706666X 706670X 32987-3 32987-3
IHC Model 60 Rear Axles
For 1200 Model
Axle B.M. 603054, 603490, 603492
VEHICLE MODEL & H u b Inner Wheel Outer Wheel Spindle Spindle Nut
BILL OF MATERIAL BASE NUMBER Bolt Nut Seal Bearing Kit Bearing Kit Nut Lockwasher
(item 30) (item 31) (item 32) (item 33) (item 34) (item 36) (item 37)
Brake Mounting
For 1000 & 1100 Models
Axle B.M. 602918, 602998, 603053 30175 30137 34419 32755 550707 32758 32762
550708
Axle B.M. 603259 30175 30137 34419 32755 565903 35239 35238
Axle B.M. 603494 30175 36880 34419 32755 565903 35239 35238
(1) Not a Kit (1 each required for all applications listed)
VEHICLE MODEL & Inboard Wheel Wheel Outboard Oil Seal
BILL OF MATERIAL BASE NUMBER Bolt Nut Shaft Bearing Bearing Shaft Retainer
Seal Retainer Ring Assembly Seal
(item 30) (item 31) (item 39) (item 40) (item 41) (item 42) (item 43)
Brake Mounting
Full-Float Design
Semi-Float Design
Contact Vehicle Manufacturer for Service
(1)
Miscellaneous Small Parts - Use With All Applications
30350 30343
32987-1 1 5 /
16
" -30 1 13 /
16
" 36 1 /
8
" 4 3 /
4
" 4" 6
32987-3 1 5 /
16
" -30 1 13 /
16
" 37 7 /
16
" 4 3 /
4
" 4" 6
34233 1 5 /
16
" -30 1 13 /
16
" 30 23 /
32
" 7 1 /
16
" 5 1 /
2
" 5
35455-3 1 5 /
16
" -30 1 13 /
16
" 31 19 /
32
" 7 1 /
16
" 5 1 /
2
" 5
35455-4 1 5 /
16
" -30 1 13 /
16
" 32 15 /
32
" 7 1 /
16
" 5 1 /
2
" 5
Axle Shaft Dimensions
Spline Bolts
Part
Number
Diameter &
Number of
Splines
Length Flange Face
to End of
Spline
Flange
Diameter
Circle
Diameter
Number of
Bolt Holes
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
