105
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
X510-9
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
Ford Model 70 Rear Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Shim – Drive Pinion
5 Baffle – Pinion Bearing
6 Shim – Pinion Bearing
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
10 (2) End Yoke Assembly
11 Washer – Pinion Nut
12 Pinion Nut
13 (2) Companion Flange Assembly
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
18 (2) Differential Bearing Cap
19 (2) Bolt – Differential Bearing Cap
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Differential Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
30 (1) Brake Mounting Bolt
31 (1) Brake Mounting Nut
32 (1) Hub Seal
33 (1) KIT – Inner Wheel Bearing
34 (1) KIT – Outer Wheel Bearing
35 (1) Wheel Hub
36 (1) Spindle Nut – Inner
37 (1) Lockwasher – Spindle Nut
38 (1) Spindle Nut – Outer
39 Shaft – Axle Flanged Drive
40 Spacer – Differential Bearing
Power-Lok & Trak-Lok
Differential
41 Flange Half - Differential Case
42 Cap Half – Differential Case
43 Shaft – Differential
44 Pinion – Differential
45 Gear – Differential
46 Ring – Differential
47 Plate – Differential
48 Disc – Differential
49 Disc – Differential (dished)
50 Plate – Differential (dished)
51 Bolt – Differential Case
