X510-9
123
Miscellaneous Small Parts- Use with All Applications
Bills of Material Description & Item Number (Refer to
"Exploded View" at the front of this section)
GMC / Chevrolet Model 44 Front Axles
602877 602878 602899 602955 603005
603004 603001
603060
Seal & Guide Tube 31 — — — — —
Seal — 32542-1 32542-1 32542-1 32542-1 32542-1
Guide — 30703 30703 30703 30703 30703
Stop Screw 39 31026-1 31026-1 31026-1 31026-1 30902
Jam Nut 40 500381-3 500381-3 500381-3 500381-3 500381-3
Oil Seal 47 — — — (3) — —
Spacer - Wheel Bearing Spindle 48 — — 35986 — —
Oil Seal - Block Vee 49 — — — — —
Needle Bearing Assembly 50 30339 30339 30339 30339 30339
Nut - Brake Mounting 52 30688 30688 ) 30688 30688 30688
Oil Seal 53 — 36369 — — 36369
Wheel Hub 55 — — (3) — — — (3)
Gasket-Drive Flange 60 — 30344 — — 30344
Flange-Axle Drive 61 — 30340 — — 30340
Snap Ring 62 31624 31624 31624 31624 31624
Hub Cap 63 — 32001 — — 32001
Nut 64 — 500371-3 — — 500371-3
Lockwasher 65 — 501209-3 — — 501209-3
Stud 66 — 31017 — — 31017
Hub Cap 67 31152 — 31152 31152 —
Axle Drive Gear 68 31125 — 31125 31125 —
Pressure Spring 69 35218 — — 35218 —
Plate-Spring Retaining 70 32589 — 26124X (9) 32589 —
Wheel Bearing Adjusting Nut 71 31139 31139 31139 31139 31139
Retaining Lock Nut 72 36569 36569 36569 36569 36569
Nut & Pin Assembly-Inner Lock 73 21588X 21588X 21588X 21588X 21588X
Wheel Hub 75 — (3) — — (3) — (3) —
Oil Seal 77 34611 — 34611 34611 —
Hub Lock Assembly N.I. 22429X 22435X 23345X 26133-3X 22435X
(3) Contact Vehicle Manufacturer
(9) Includes Pressure Spring
