X510-9
141
Kits & Parts — Use with All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
603728 610033
Inner Pinion Bearing Kit 4 706046X 706046X
Pinion & Bearing Adjusting Shim 706672X 706672X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim 706674X 706674X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing 8 706045X 706045X
Carrier Cover (inc. 15, 16, 17, 18) 706128X 706128X
Differential Bearing Adj. Shim (16, 22) 706673X 706673X
Differential Bearing 21 706047X 706047X
Seal & Guide Tube 31 36487 36487
Seal — Upper King Pin 32 620058 620058
KIT — King Pin Parts (inc. 32,33,34,35) N.I. 706395X 706395X
Stop Screw 36 31026-1 31026-1
Jam Nut 37 500381-3 500381-3
Cotter Pin 39 500024-4 500024-4
Lube Fitting 40 500175-4 500175-4
Nut — Hex Tapered 41 30875 30875
Steering Arm (LH only) 43 38139 38139
Cap — Upper King Pin (RH only) " 620132 620132
Gasket — King Pin Cap 44 37307 37307
Compression Spring 45 37300 37300
Retainer Spring 46 — 620180
Bushing — King Pin 47 37301 37301
King Pin 48 — 37302
Knuckle Assembly (RH only) 49 29729X 29729X
Knuckle Assembly (LH only) N.I. 29730X 29730X
Cap — Lower King Pin (RH only) 50 37299 37299
Lockwasher — Lower King Pin Cap 51 500357-13 500357-13
Hex Bolt — Lower King Pin Cap 52 500412-12 500412-12
KIT — Wheel Spindle Seal & Bearing N.I. 700014 700014
(inc. items 55, 56, 57, 58)
KIT — Wheel Bearing Spindle N.I. 700013 700013
(inc. items 57, 58, 59)
Nut — Brake Mounting 60 36880 36880
Washer — Brake Mounting N.I. 38081-1 38081-1
Oil Seal 61 37729 37729
Inner Wheel Bearing 62 706411X 706411X
Outer Wheel Bearing 63 706074X 706074X
Nut — Wheel Bearing Inner 65 33732 33732
Washer — Wheel Bearing Inner N.I. 33734 33734
Retaining Lock Nut 66 33733 33733
Nut — Wheel Bearing Outer 67 33732 33732
Spring Retaining Plate / Spacer 68 37997 37997
Axle Drive Gear 70 37994 37994
Snap Ring 71 37730 37730
Hub Cap 72 37996 37996
GMC / Chevrolet Model 60 Front Axles
