X510-8
146
For C10 Models
Axle B.M. 602994, 603006, 603050,
603145, 603146
For C15 & I1000 Models
Axle B.M. 602926
For C20, C25, I1500, K1500, K25 Models
Axle B.M. 602923, 602927, 602989,
602995, 603033, 603051, 603067,
603073, 603107, 603206, 603207,
603208, 603209, 603320, 603321,
603322, 603323
For B-Body Model
30175 30137 (2) (2) 706074X 33732 33733
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
ITEM DESCRIPTION KIT PART
NO. NUMBER
ITEM DESCRIPTION KIT PART
NO. NUMBER
Carrier Cover 706128X
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Carrier Cover Plug
17 Carrier Cover Bolt
Inner Pinion Bearing 706046X
3 KIT – Inner Pinion Bearing
Outer Pinion Bearing 706045X
7 KIT – Outer Pinion Bearing
Outer Pinion Bearing 706047X
20 KIT – Differential Bearing
Pinion & Bearing Adjusting Shim 706672X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
Differential Bearing Adjusting Shim 706673X
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
Differential & Pinion Shim 706674X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
VEHICLE MODEL & H u b Inner Wheel Outer Wheel Spindle Spindle Nut
BILL OF MATERIAL BASE NUMBER Bolt Nut Seal Bearing Kit Bearing Kit Nut Lockwasher
(item 30) (item 31) (item 32) (item 33) (item 34) (item 36) (item 37)
BRAKE MOUNTING
30235-1 35704 34419 35755 33388
30175 30173 34419 35827 550317 30388 30428
(1) Not a Kit (1 each required for all applications listed)
(2) Contact Vehicle Manufacturer for Service
LH - Left Hand RH - Right Hand
VEHICLE MODEL & Inboard Wheel Bearing Wheel Bearing Outboard Oil Seal
BILL OF MATERIAL BASE NUMBER Bolt Nut Shaft Seal Retainer Ring Assembly Shaft Seal Retainer
(item 30) (item 31) (item 39) (item 40) (item 41) (item 42) (item 43)
BRAKE MOUNTING
Full-Float Design
Semi-Float Design
(1)
GMC / Chevrolet Model 60 Rear Axles
500411-10 500641 35697 706217X 306636 30637 (1)
550189
550232
Axle B.M. 603398, 603475, 603545,
603560, 603702, 603705, 603884
550707 33382 (RH)
550708 23913X (LH)
Miscellaneous Small Parts - Use With All Applications
Common Axle Kits - Use with All Applications
