Page 211
205
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
X510-9
ITEM
PART IDENTIFICATION
NO.
Parts Listing
ITEM
PART IDENTIFICATION
NO.
ITEM
PART IDENTIFICATION
NO.
IHC Model 70 Rear Axles
1
(1)
Housing – Axle Service
2
Drive Pinion & Gear Assembly
3
KIT – Inner Pinion Bearing
4
Shim – Drive Pinion
5
Baffle – Pinion Bearing
6
Shim – Pinion Bearing
7
KIT – Outer Pinion Bearing
8
Slinger – Outer Pinion Bearing
9
Seal – Pinion Oil
10
(2)
End Yoke Assembly
11
Washer – Pinion Nut
12
Pinion Nut
13
(2)
Companion Flange Assembly
14
Carrier Cover
15
Carrier Cover Gasket / Sealant
16
Plug – Carrier Cover
17
Bolt – Carrier Cover
18
(1)
Differential Bearing Cap
19
(1)
Bolt – Differential Bearing Cap
20
KIT – Differential Bearing
21
Shim – Differential Bearing
22
Case – Differential
23
Bolt – Drive Gear
24
Pinion – Differential
25
Gear – Differential
26
Thrustwasher – Diff. Pinion
27
Thrustwasher – Differential Gear
28
Shaft – Differential Pinion
29
Lock – Differential Shaft
30
(1)
Brake Mounting Bolt
31
(1)
Brake Mounting Nut
32
(1)
Hub Seal
33
(1)
KIT – Inner Wheel Bearing
34
(1)
KIT – Outer Wheel Bearing
35
Wheel Hub
36
(1)
Spindle Nut – Inner
37
(1)
Lockwasher – Spindle Nut
38
(1)
Spindle Nut – Outer
39
Shaft – Axle Flanged Drive
40
Spacer – Differential Bearing
Power-Lok & Trak-Lok
Differential
41
Flange Half - Differential Case
42
Cap Half – Differential Case
43
Shaft – Differential
44
Pinion – Differential
45
Gear – Differential
46
Ring – Differential
47
Plate – Differential
48
Disc – Differential
49
Disc – Differential (dished)
50
Plate – Differential (dished)
51
Bolt – Differential Case
Drive Pinion & Gear Assembly
2
Drive Pinion & Gear Assembly
3
KIT – Inner Pinion Bearing
4
Inner Pinion Shims
5
Baffle – Pinion Bearing
6
Outer Pinion Shims
7
KIT – Outer Pinion Bearing
8
Slinger – Outer Pinion Bearing
9
Seal – Pinion Oil
11
Washer – Pinion Nut
12
Pinion Nut
15
Carrier Cover Gasket / Sealant
21
Shim – Differential Bearing
23
Bolt – Drive Gear
40
Spacer – Differential Bearing
Differential Case Assembly (Powr-Lok)
16
Carrier Cover Gasket / Sealant
20
KIT – Differential Bearing
21
Shim – Differential Bearing
23
Bolt – Drive Gear
40
Spacer – Differential Bearing
41
Flange Half – Differential Case
42
Cap Half – Differential Case
43
Shaft – Differential
44
Pinion – Differential
45
Gear – Differential
46
Ring – Differential Gear
47
Plate – Differential
48
Disc – Differential
49
Disc – Differential (dished)
50
Plate – Differential (dished)
51
Bolt – Differential Case
Differential Case (Powr-Lok)
15
Carrier Cover Gasket / Sealant
21
Shim – Differential Bearing
23
Bolt – Drive Gear
41
Flange Half – Differential Case
42
Cap Half – Differential Case
51
Bolt – Differential Case
Differential Parts (Powr-Lok)
43
Shaft – Differential
44
Pinion – Differential
45
Gear – Differential
46
Ring – Differential Gear
47
Plate – Differential
48
Disc – Differential
49
Disc – Differential (dished)
50
Plate – Differential (dished)
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
ITEM
DESCRIPTION
NO.
Kit Components
ITEM
DESCRIPTION
NO.
ITEM
DESCRIPTION
NO.
