X510-8
24
For Retail Maintenance, D200 & W200, B300, CB300 & MB300, M300 & RM300 Models
Axle B.M. 602423, 603010, 603016,
603160, 603236, 603237, 603313,
603341, 603376, 603514, 603516,
603645, 603647, 603648, 603650,
603768, 603769, 603774, 603775,
603831, 603832, 603892
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
Common Axle Kits - Use with All Applications
ITEM DESCRIPTION KIT PART
NO. NUMBER
ITEM DESCRIPTION KIT PART
NO. NUMBER
Inner Pinion Bearing 706046X
3 KIT – Inner Pinion Bearing
Outer Pinion Bearing 706045X
7 KIT – Outer Pinion Bearing
Outer Pinion Bearing 706047X
20 KIT – Differential Bearing
Pinion & Bearing Adjusting Shim 706672X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
Differential Bearing Adjusting Shim 706673X
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
Differential & Pinion Shim 706674X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
VEHICLE MODEL & H U B INNER WHEEL OUTER WHEEL SPINDLE SPINDLE NUT
BILL OF MATERIAL BASE NUMBER BOLT NUT SEAL BEARING KIT BEARING KIT NUT LOCKWASHER
(item 30) (item 31) (item 32) (item 33) (item 34) (item 33) (item 37)
BRAKE MOUNTING
For B-Body Model
Axle B.M. 602875 34183 34184 (2) (2) (2) 34177 34181
For B-Body & E-Body Models
Axle B.M. 602957, 603080,
34183 34184 34419 32755
550707
34177 34181
603109, 603222, 603226, 603425
550708
(1) Not a Kit (1 each required for all applications listed)
(2) Contact Vehicle Manufacturer for Service
VEHICLE MODEL & INBOARD WHEEL WHEEL OUTBOARD OIL SEAL
BILL OF MATERIAL BASE NUMBER BOLT NUT SHAFT BEARING BEARING SHAFT RETAINER
SEAL RETAINER RING ASSEMBLY SEAL (item 43)
(item 30) (item 31) (item 39) (item 40) (item 41) (item 42)
BRAKE MOUNTING
Full-Float Design
Semi-Float Design
(Contact Vehicle Manufacturer for Service)
(1)
Dodge Model 60 Rear Axles
Miscellaneous Small Parts - Use With All Applications
