Ford model 44 rear axles, Exploded view, Miscellaneous small parts – Spicer Front and Rear Axle Catalog User Manual
Page 78
X510-9
72
Exploded View
Ford Model 44 Rear Axles
For F100 Model
Axle B.M. 602909, 602964
30175
30137
34419
32755
32758
—
(3)
Axle B.M. 603830
—
(3)
36880
34419
32755
565903
35239
35238
Axle B.M. 603869, 603903
38998
30137
34419
38888
565903
35239
35238
(3)
Contact Vehicle Manufacturer for Service
(10) Not a Kit (1 each required for applications listed)
VEHICLE MODEL &
Inboard
Wheel Bearing
Wheel Bearing
Outboard
Oil Seal
BILL OF MATERIAL BASE NUMBER
Bolt
Nut
Shaft Seal
Retainer Ring
Assembly
Shaft Seal
Retainer
(item 30)
(item 31)
(item 32)
(item 33)
(item 34)
(item 35)
(item 36)
Brake Mounting
Miscellaneous Small Parts
550707
550708
(10)
