Dodge model 70 front axles, Kit components, Axle shaft dimensions – Spicer Front and Rear Axle Catalog User Manual
Page 208
X510-8
202
Dodge Model 70 Front Axles
Drive Pinion & Gear Assembly
2
Drive Pinion & Gear Assembly
3
KIT – Inner Pinion Bearing
4
Inner Pinion Shims
5
Baffle – Pinion Bearing
6
Outer Pinion Shims
7
KIT – Outer Pinion Bearing
8
Slinger – Outer Pinion Bearing
9
Seal – Pinion Oil
11
Washer – Pinion Nut
12
Pinion Nut
15
Carrier Cover Gasket / Sealant
21
Shim – Differential Bearing
23
Bolt – Drive Gear
Differential Case Assembly (standard)
(1 piece Case)
15
Carrier Cover Gasket / Sealant
20
KIT – Differential Bearing
21
Shim – Differential Bearing
22
Case – Differential
23
Bolt – Drive Gear
24
Pinion – Differential
25
Gear – Differential
26
Thrustwasher – Diff. Pinion
27
Thrustwasher – Diff. Gear
28
Shaft – Differential Pinion
29
Lock – Differential Shaft
Differential Case Assembly (standard)
(2 piece Case)
15
Carrier Cover Gasket / Sealant
20
KIT – Differential Bearing
21
Shim – Differential Bearing
23
Bolt – Drive Gear
24
Pinion – Differential
25
Gear – Differential
26
Thrustwasher – Diff. Pinion
27
Thrustwasher – Differential Gear
72
Flange Half – Differential Case
73
Cap Half – Differential Case
74
Shaft – Differential Pinion
82
Bolt – Differential Case
Differential Case Assembly (Powr-Lok)
15
Carrier Cover Gasket / Sealant
20
KIT – Differential Bearing
21
Shim – Differential Bearing
23
Bolt – Drive Gear
72
Flange Half – Differential Case
73
Cap Half – Differential Case
74
Shaft – Differential
75
Pinion – Differential
76
Gear – Differential
77
Ring – Differential Gear
78
Plate – Differential
79
Disc – Differential
80
Disc – Differential (dished)
81
Plate – Differential (dished)
82
Bolt – Differential Case
Differential Case (standard)
(1 piece Case)
15
Carrier Cover Gasket / Sealant
21
Shim – Differential Bearing
22
Case – Differential
23
Bolt – Drive Gear
29
Lock – Differential Shaft
Differential Case (standard)
(2 piece Case)
15
Carrier Cover Gasket / Sealant
21
Shim – Differential Bearing
23
Bolt – Drive Gear
72
Flange Half – Differential Case
73
Cap Half – Differential Case
82
Bolt – Differential Case
Differential Case (Powr-Lok)
15
Carrier Cover Gasket / Sealant
21
Shim – Differential Bearing
23
Bolt – Drive Gear
72
Flange Half – Differential Case
73
Cap Half – Differential Case
82
Bolt – Differential Case
Differential Parts (standard)
(1 piece Case)
15
Carrier Cover Gasket / Sealant
23
Bolt – Drive Gear
24
Pinion – Differential
25
Gear – Differential
26
Thrustwasher – Diff. Pinion
27
Thrustwasher – Diff. Gear
28
Shaft – Differential Pinion
29
Lock – Differential Shaft
Differential Parts (standard)
(2 piece Case)
15
Carrier Cover Gasket / Sealant
23
Bolt – Drive Gear
24
Pinion – Differential
25
Gear – Differential
26
Thrustwasher – Diff. Pinion
27
Thrustwasher – Diff. Gear
74
Shaft – Differential Pinion
Differential Parts (Powr-Lok)
15
Carrier Cover Gasket / Sealant
74
Shaft – Differential
75
Pinion – Differential
76
Gear – Differential
77
Ring – Differential Gear
78
Plate – Differential
79
Disc – Differential
80
Disc – Differential (dished)
81
Plate – Differential (dished)
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
ITEM
DESCRIPTION
NO.
Kit Components
ITEM
DESCRIPTION
NO.
Axle Shaft Dimensions
Inner Shaft - Side Gear End
Outer Shaft - Spline End
Axle Shaft & Joint Assembly
Complete
Assembly
Number
Major
Spline
Diameter
Centerline
to End of
Spline
Yoke Shaft
Part
Number
Major
Spline
Diameter
Centerline
to End of
Spline
Yoke Shaft
Part
Number
Side
Overall
Length
Cross &
Bearing Kit
902252-1
1
1
/
2
" -35
24
3
/
16
"
3-82-581-1
1
1
/
2
" -35
11
1
/
32
"
3-82-591
Right
35
7
/
32
"
5-88X
902252-2
1
1
/
2
" -35
39
1
/
2
"
3-82-581-2
1
1
/
2
" -35
11
1
/
32
"
3-82-591
Left
50
31
/
32
"
5-88X
903670-1
1
1
/
2
" -35
18
5
/
16
"
3-82-641-1
1
3
/
8
" -21
11
1
/
32
"
3-82-461-1 Right
29
11
/
32
"
5-88X
903670-2
1
1
/
2
" -35
35
7
/
16
"
3-82-641-2
1
3
/
8
" -21
11
1
/
32
"
3-82-461-1
Left
46
15
/
32
"
5-88X
ITEM
DESCRIPTION
NO.
