X510-8
215
AMC/Jeep Model 30 Rear Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Inner Pinion Bearing Shims
5 Baffle – Pinion Bearing
6 Outer Pinion Bearing Shims
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
10 (2) End Yoke Assembly
11 Washer – Pinion Nut
12 Pinion Nut
13 (2) Companion Flange Assembly
14 Carrier Cover
15 Gasket – Carrier Cover
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
18 (1) Cap – Differential Bearing
19 (1) Bolt – Differential Bearing Cap
20 KIT – Differential Bearing
21 PKG – Diff Bearing Shim (inc 15)
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff Pinion
27 Thrustwasher – Diff Gear
28 Shaft – Differential
29 Lock – Differential Shaft
30 (1) Bolt – Brake Mounting
31 Nut – Brake Mounting
32 Seal – Inboard Shaft
33 Retainer Ring – Wheel Bearing
34 Wheel Bearing Assembly
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
Common Axle Kits - Use with All Applications
ITEM DESCRIPTION KIT PART
NO. NUMBER
ITEM DESCRIPTION KIT PART
NO. NUMBER
Carrier Cover 706013X
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Carrier Cover Plug
17 Carrier Cover Bolt
Inner Pinion Bearing 706015X
3 KIT – Inner Pinion Bearing
Outer Pinion Bearing 706014X
7 KIT – Outer Pinion Bearing
Differential Bearing 706016X
20 KIT – Differential Bearing
Pinion & Bearing Adjusting Shim 706360X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
Differential Bearing Adjusting Shim 706087X
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
Differential & Pinion Shim 706386X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
35 Seal – Outboard Shaft
36 Retainer – Oil Seal
37 (1) Axle Shaft Assembly
Power-Lok & Trak-Lok
Differential
38 Flange Half – Differential Case
39 Cap Half – Differential Case
40 Shaft – Differential
41 Pinion – Differential
42 Gear – Differential
43 Ring – Differential Gear
44 Plate – Differential
45 Disc – Differential
46 Disc – Differential (dished)
47 Plate – Differential (dished)
48 Bolt – Differential Case
