Spicer Front and Rear Axle Catalog - Manual (Page 132)

X510-9
126
Miscellaneous Small Parts- Use with All Applications
Bills of Material
Description & Item Number (Refer to
"Exploded View" at the front of this section)
603676 603707 603792 610036
603793 610037
Seal & Guide Tube 31 620216 36352 620216 620216
Seal — — — 32542-1 32542-1
Guide — — — 30703 30703
Stop Screw 39 31026-1 31026-1 31026-1 31026-1
Jam Nut 40 500381-3 500381-3 500381-3 500381-3
Oil Seal 47 38128 38128 38128 38128
Spacer - Wheel Bearing Spindle 48 38106 38106 38106 38106
Oil Seal - Block Vee 49 36361 36361 36361 36361
Needle Bearing Assembly 50 550759 550759 550759 550759
Nut - Brake Mounting 52 35704 35704 35704 35704
Oil Seal 53 36369 30348 — —
Wheel Hub 55 — (3) — (3) — —
Gasket-Drive Flange 60 35419 35419 — —
Flange-Axle Drive 61 30340 30340 — —
Snap Ring 62 31624 31624 31624 31624
Hub Cap 63 32001 32001 — —
Nut 64 38107 38107 — —
Lockwasher 65 — — — —
Stud 66 — — — —
Hub Cap 67 — — 36858 36858
Axle Drive Gear 68 — — 620138 620138
Pressure Spring 69 — — 35218 35218
Plate-Spring Retaining 70 — — 32589 32589
Wheel Bearing Adjusting Nut 71 31139 31139 31139 31139
Retaining Lock Nut 72 36569 36569 36569 36569
Nut & Pin Assembly-Inner Lock 73 21588X 21588X 21588X 21588X
Wheel Hub 75 — — — (3) — (3)
Oil Seal 77 — — 36366 36366
Hub Lock Assembly N.I. 27369-3X 27369-3X 26133-3X 26133-3X
GMC / Chevrolet Model 44 Front Axles
(3) Contact Vehicle Manufacturer
