Spicer Front and Rear Axle Catalog - Manual (Page 233)

X510-9
227
Kits & Small Parts - Use with All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
603685 610014
610017
Carrier Cover (inc. 15, 16, 17, 18) — 706141X 706141X
Seal & Guide Tube 31 620216 36352
Seal — — —
Guide — — —
Steering Knuckle Assembly - RH — 706575X 706134X
(inc. items 32, 33, 34, 36, 41)
Steering Knuckle Assembly - LH N.I. 706576X 706143X
Socket Assy (32,33,34,35,36,37,38) 706116X 706116X
Stop Screw 39 31026-1 31026-1
Jam Nut 40 500381-3 500381-3
Wheel Spindle Seal & Bearing 706527X 706527X
(inc. items 47, 48, 49, 50)
Wheel Bearing Spindle 706570X 706570X
(inc. items 47, 48, 49, 50, 51 or 78)
Oil Seal 47 38128 38128
Spacer - Wheel Bearing Spindle 48 38106 38106
Oil Seal - Block Vee 49 36361 36361
Needle Bearing Assembly 50 550759 550759
Nut - Brake Mounting 52 35704 35704
Oil Seal 53 — —
Inner Wheel Bearing 54/76 706074X — (3)
Wheel Hub 55 — —
Outer Wheel Bearing 56/74 706111X 706111X
Lockwasher-Wheel Bearing 57 — —
Nut-Wheel Bearing 58 — —
Lockwasher-Wheel Bearing Nut 59 — —
Gasket-Drive Flange 60 — —
Flange-Axle Drive 61 — —
Snap Ring 62 31624 31624
Hub Cap 63 — —
Nut 64 — —
Lockwasher 65 — —
Stud 66 — —
Hub Cap 67 31152 31152
Axle Drive Gear 68 620138 620138
Pressure Spring 69 35218 35218
Plate-Spring Retaining 70 32589 32589
Wheel Bearing Adjusting Nut 71 31139 31139
Retaining Lock Nut 72 36569 36569
Nut & Pin Assembly-Inner Lock 73 21588X 21588X
Wheel Hub 75 — (3) — (3)
Oil Seal 77 36366 36366
Hub Lock Assembly N.I. 26133-3X 26133-3X
(3) Contact Vehicle Manufacturer
AMC/Jeep Model 44 Front Axles
