Hydraulic Pipe Bender
The machine serial number is located on the side of the
pump. The last 4 digits indicates the month and year of
the manufacture. (03 = month, 10 = year).
NOTICE
Selection of appropriate materials and instal-
lation, joining and forming methods is the responsibil-
ity of the system designer and/or installer. Selection of
improper materials and methods could cause system
failure.
Stainless steel and other corrosion resistant materials
can be contaminated during installation, joining and
forming. This contamination could cause corrosion and
premature failure. Careful evaluation of materials and
meth ods for the specific service conditions, including
chemical and temperature, should be completed before
any installation is attempted.
Specifications
Pipe Bender
Operating Temperature: 23°F to 122°F (-5°C to 50°C) (See Maintenance Section for more information.)
Model
No.
Capacity
Inch
Pump
Pressure
(bar)
Ram Force
kN(klb)
Pump
Type
Motor
Approximate Equip-
ment Dimensions
L x W x H (cm)
Standard
Formers
Shipping
Weight
Crate
Dimensions
L x W x H (cm)
Volt &
Frequency
Power
kW
lb kg
HB382
3
/
8
" - 2"
450
90 (20.1) Manual
N/A
N/A
73 x 63,5 x 62
3
/
8
",
1
/
2
",
3
/
4
", 1", 159 72
82 x 33 x 49,5
28.8" x 25" x 24.4"
1
1
/
4
", 1
1
/
2
", 2"
32.3" x 13" x 19.5"
HB382E
3
/
8
" - 2"
450
90 (20.1) Electric 230/50Hz 1Φ
1.4
73 x 63,5 x 43
3
/
8
",
1
/
2
",
3
/
4
", 1", 211 96
82 x 39,5 x 60
230/60Hz 3Φ
1.5
28.8" x 25" x 16.9"
1
1
/
4
", 1
1
/
2
", 2"
32.3" x 15.6" x 23.6"
115/60Hz 1Φ
1.4
400/50Hz 3Φ
1.5
HB383
3
/
8
" - 3"
450
146 (32.7) Manual
N/A
75,5 x 103 x 62
3
/
8
",
1
/
2
",
3
/
4
", 1", 344 156
117 x 37,5 x 49,5
29.8" x 40.6" x 24.4"
1
1
/
4
", 1
1
/
2
", 2",
2
1
/
2
", 3
46.1" x 14.8" x 19.5"
HB383E
3
/
8
" - 3"
450
146 (32.7) Electric 230/50Hz 1Φ
1.4
75,5 x 103 x 62
3
/
8
",
1
/
2
",
3
/
4
", 1" 401 182
117 x 46,5 x 62
230/60Hz 3Φ
1.5
29.8" x 40.6" x 24.4"
1
1
/
4
", 1
1
/
2
", 2",
2
1
/
2
", 3
46.1" x 18.3" x 24.1"
115/60Hz 1Φ
1.4
400/50Hz 3Φ
1.5
Figure 3 – Machine Serial Number
Date Code
