ZyWALL 2 Series User’s Guide
WAN Screens 6-9
Table 6-6 PPTP Encapsulation
LABEL DESCRIPTION
User Name Type the user name given to you by your ISP.
Password Type the password associated with the User Name above.
Retype to Confirm Type your password again to make sure that you have entered is correctly.
Nailed-up
Connection Select Nailed-Up Connection if you do not want the connection to time out.
Idle Timeout This value specifies the time in seconds that elapses before the ZyWALL
automatically disconnects from the PPTP server.
PPTP Configuration
My IP Address Type the (static) IP address assigned to you by your ISP.
My IP Subnet Mask Your ZyWALL will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the subnet
mask computed by the ZyWALL.
Server IP Address Type the IP address of the PPTP server.
Connection ID/Name Type your identification name for the PPTP server.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
6.6 Configuring WAN IP
To change your ZyWALL’s WAN IP settings, click WAN, then the WAN IP tab. This screen varies
according to the type of encapsulation you select.
If your ISP did not assign you a fixed IP address, click Get automatically from ISP (Default);otherwise
click Use fixed IP Address and enter the IP address in the following field.
When Network Address Translation is set to Full Feature, but there is no NAT rule
configured, the warning message “Warning! No NAT rule configured in system”
appears in the status bar.
