ZyWALL 2 Series User’s Guide
Remote Node Setup 26-7
26.3 Edit IP
Move the cursor to the Edit IP field in menu 11.1, then press [SPACE BAR] to select Yes. Press [ENTER]
to open Menu 11.3 - Network Layer Options.
Figure 26-4 Menu 11.3: Remote Node Network Layer Options for Ethernet Encapsulation
This menu displays the My WAN Addr field for PPPoE and PPTP encapsulations and Gateway IP Addr
field for Ethernet encapsulation. The following table describes the fields in this screen.
Table 26-4 Remote Node Network Layer Options Menu Fields
FIELD DESCRIPTION EXAMPLE
IP Address
Assignment If your ISP did not assign you an explicit IP address, press [SPACE BAR]
and then [ENTER] to select Dynamic; otherwise select Static and enter
the IP address & subnet mask in the following fields. Dynamic
(default)
(Rem) IP
Address If you have a Static IP Assignment, enter the IP address assigned to you
by your ISP.
(Rem) IP
Subnet Mask If you have a Static IP Assignment, enter the subnet mask assigned to
you.
Gateway IP
Addr This field is applicable to Ethernet encapsulation only. Enter the gateway
IP address assigned to you if you are using a static IP address.
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Addr= N/A
Network Address Translation= SUA Only
Metric= 1
Private=
RIP Direction= None
Version= N/A
Multicast= None
Enter here to CONFIRM or ESC to CANCEL:
