ZyWALL 2 Series User’s Guide
Internet Access 25-5
Figure 25-3 Internet Access Setup (PPPoE)
The following table contains instructions about the new fields when you choose PPPoE in the
Encapsulation field in menu 4.
Table 25-3 New Fields in Menu 4 (PPPoE) screen
FIELD DESCRIPTION EXAMPLE
Encapsulation Press [SPACE BAR] and then press [ENTER] to choose PPPoE. The
encapsulation method influences your choices in the IP Address field. PPPoE
Idle Timeout This value specifies the time in seconds that elapses before the ZyWALL
automatically disconnects from the PPPoE server. 100
(default)
If you need a PPPoE service name to identify and reach the PPPoE server, please go to menu 11 and enter the
PPPoE service name provided to you in the Service Name field.
25.5 Basic Setup Complete
Well done! You have successfully connected, installed and set up your ZyWALL to operate on your network
as well as access the Internet.
When the firewall is activated, the default policy allows all communications to the
Internet that originate from the LAN, and blocks all traffic to the LAN that
originates from the Internet.
You may deactivate the firewall in menu 21.2 or via the ZyWALL embedded web configurator. You may
also define additional firewall rules or modify existing ones but please exercise extreme caution in doing so.
See the firewall chapters for more information on the firewall.
Menu 4 - Internet Access Setup
ISP's Name= ChangeMe
Encapsulation= PPPoE
Service Type= N/A
My Login=
My Password= ********
Retype to Confirm= ********
Idle Timeout= 100
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Address= N/A
Network Address Translation= SUA Only
Press ENTER to Confirm or ESC to Cancel:
