ZyWALL 2 Series User’s Guide
Certificates 15-29
15.16 Directory Servers
Click CERTIFICATES, Directory Servers to open the Directory Servers screen. This screen displays a
summary list of directory servers (that contain lists of valid and revoked certificates) that have been saved
into the ZyWALL. If you decide to have the ZyWALL check incoming certificates against the issuing
certification authority’s list of revoked certificates, the ZyWALL first checks the server(s) listed in the CRL
Distribution Points field of the incoming certificate. If the certificate does not list a server or the listed
server is not available, the ZyWALL checks the servers listed here.
Figure 15-12 Directory Servers
The following table describes the labels in this screen.
Table 15-13 Directory Servers
LABEL DESCRIPTION
PKI Storage
Space in Use This bar displays the percentage of the ZyWALL’s PKI storage space that is currently
in use. When you are using 80% or less of the storage space, the bar is green. When
the amount of space used is over 80%, the bar is red. When the bar is red, you
should consider deleting expired or unnecessary certificates before adding more
certificates.
# The index number of the directory server. The servers are listed in alphabetical order.
Name This field displays the name used to identify this directory server.
Address This field displays the IP address or domain name of the directory server.
