ZyWALL 2 Series User’s Guide
37-2 VPN/IPSec Setup
Figure 37-2 Menu 27: VPN/IPSec Setup
37.2 IPSec Summary Screen
Type 1 in menu 27 and then press [ENTER] to display Menu 27.1 — IPSec Summary. This is a summary
read-only menu of your IPSec rules (tunnels). Edit or create an IPSec rule by selecting an index number and
then configuring the associated submenus.
Figure 37-3 Menu 27.1: IPSec Summary
The following table describes the fields in this screen.
Table 37-1 Menu 27.1: IPSec Summary
FIELD DESCRIPTION EXAMPLE
# This is the VPN policy index number. 1
Menu 27 - VPN/IPSec Setup
1. IPSec Summary
2. SA Monitor
Enter Menu Selection Number:
Menu 27.1 - IPSec Summary
# Name A Local Addr Encap IPSec Algorithm
Key Mgt Remote Addr Start - Addr End / Mask Secure Gw Addr
--- ---------- - ----------------- ----------------- ------ ----------------
001 taiwan Y 192.168.1.35 192.168.1.38 Tunnel ESP DES-SHA1
IKE 172.16.2.40 172.16.2.46 193.81.13.2
002 zw2 N 1.1.1.1 1.1.1.1 Tunnel AH SHA1
IKE 4.4.4.4 255.255.0.0 zw2test.zyxel
Select Command= None Select Rule= N/A
Press ENTER to Confirm or ESC to Cancel:
