Automated Solutions
Power Wave
®
455M Robotic Processes
• MIG
• Pulsed
• STT
®
• Flux-Cored
Output Input
Key Options
• K2207-2 Ethernet/DeviceNet
™
Interface Module
• K1570-1 Dual Cylinder Platform
Undercarriage
• K1813-1 Cool-Arc ™ 40 115/1/50/60
• More options at end of section
Wire Feeders
• K1780-2 Power Feed
™ 10R
• K2685-2 AutoDrive 4R90
Literature
E10.90
DC 3
PHASE
60
50
Hz
CV
CC
Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Current /Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power Wave ® K2262-1 208/230/460/575/3/50/60 60Hz: 60Hz: 5-570A 26.1 x 19.9 x 32.9 286
455M Robotic 450A/38V/100% 58/53/25/22A (663 x 505 x 835) (130)
(570A/43V/60%) (82/78/37/31A)
50Hz: 50Hz:
400A/36V/100% 49/45/23/18A
(500A/40V/60%) (67/61/31/25A)
The Power Wave ® 455M Robotic is a high performance, digitally
controlled inverter power source designed for robotic, hard
automation and semiautomatic applications.
• Program your own waveform or choose from over 60
standard welding waveform programs.
• Optional communication modules provide networking
capabilities via DeviceNet ™ or Ethernet.
• Utilizes ArcLink ® —the leading digital communication
protocol for welding, making it the best choice for
seamless, time critical integration to the power source
and networked equipment.
• Software based controls can be upgraded as new
features become available.
• Process and production monitoring with access to
real time (500Hz) feedback.
• A Power Wave ® inverter operates at a high efficiency
(88-90%) with a 95% minimum power factor (at rated
output) and is capable of operating from a universal
input voltage (208 to 575 volts).
Semiautomatic Automation Submerged Arc
