www.lincolnelectric.com/mig-welders
MIG: Wire Feeder/Welders
Power MIG ® 350MP
When you want more than just a MIG machine, the Power MIG ® 350 MP is the choice for you.
Lincoln’s ® Chopper Technology ® delivers more welding processes: stick, TIG, MIG, flux-
cored, and advanced processes such as Power Mode ® and Pulse-On-Pulse ® . With the simplicity
and sophistication of synergic control, no other wire feeder/welder offers so much!
The Professional’s Choice! SM
• Pulse-on-Pulse ® improves cleaning action when welding aluminum
and delivers a TIG-like appearance to the weld beads.
• Synergic control of voltage and wire feed speed allows
you to set weld procedures with one control.
• Push-Pull or Spool Gun Ready—A second gas solenoid
and other electronics are built-in to drive either a spool
gun or push-pull gun.
• 115V auxiliary receptacle powers a grinder or other equipment.
• Dual Procedure capable—select between either two
welding procedures or two welding modes.
• Rugged cast aluminum industrial wire drive features dual
driven rolls, regulated wire feed speed control, easy-turn
numeric tension indicator, brass-to-brass connections and
Lincoln’s
® 100% wire supporting split wire guide system.
• Base Unit Includes: Power MIG ® 350 MP ;
Magnum ® 300 Gun & 15 ft. (4.5m) Cable;
.035"/.045" (0.9/1.2 mm) Drive Rolls & Guide
for Steel; Regulator & Hose; Work Clamp
& Cable; 230V Input Cord & Plug.
• Three-year warranty on parts and labor.
(90 days on gun.)
(1) 40% on 208V input. Ratings based on 60 Hz operation.
Processes
• Stick
• TIG
• MIG
• Pulsed
• Flux-Cored
Output Input
Push-Pull One-Pak ® Includes
• Power MIG ® 350MP (K2403-1)
• Python ® - Plus Push-Pull Gun,
25 ft. (7.6 m)
• 3/64" Aluminum Drive Roll Kit
• Magnum
® 300 Gun, 15 ft. (4.5m)
• Cable Liner
• Contact Tips
• Work Clamp and Cable
• Adjustable Gas Regulator & Hose
Key Options
• K1702-1 Dual Cylinder Kit
• K2378-1 Medium Canvas Cover
• K2447-2 Python
® - Plus Push-Pull
Gun, 25 ft. (7.6 m)
• K2490-1 Magnum ® 250LX Spool
Gun
• More options at end of section
Literature
E7.57
DC 1
PHASE
60
Hz CV
CC
Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Voltage/Phase/Hertz Current /Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power MIG ® 350 MP K2451-2 208/230/460/575/1/50/60 300A/32V/60% (1) 72/62/31/25A 5-350 Amps DC — —
Push-Pull One-Pak ® 50-700 ipm WFS
Power MIG ® 350 MP K2403-1 (1.3 -17.7 m/min) 31.8 x 18.9 x 38.8 255
Max. OCV: 67 (808 x 408 x 985) (116)
23
