Power Arc
®
5500
The Power Arc ® 5500 is ideal for home, farm, contractors, maintenance, or business power
outage emergencies. You get two great tools in one for double the value—125 amps of AC
welding output and maximum AC generator power in a lightweight package—that makes
it easy to get auxiliary power where you need it – fast!
It’s Two Tools in One!
• 125 amps AC welding output is ideal for
3/32" (2.4 mm) and 1/8" (3.2 mm) diameter
stick electrodes.
• Sizable 5500 watts surge (4000 watts
continuous) single phase AC generator
power keeps your lights, tools, heaters,
sump pumps or appliances running during
emergencies or for any project—any time,
anywhere!
• Rugged tube frame roll cage adds protection
and many lift handle points.
• Choice of two 9 HP engines with cast iron
sleeves for long engine life:
- Subaru Robin ® OHC (Overhead Cam)
- Honda ® OHV (Overhead Valve)
• Three-year warranty on welder. (Engine is
warranted separately by the manufacturer.)
Weldanpower
®
125
Versatile Welder and AC Power Generator for Year-Round Projects
Processes
• Stick
Output Input
Key Options
• K875 Accessory Kit, 150 Amp
• K882-2 Hand Moving
Undercarriage (2 wheels)
Literature
E6.51
AC CC 5.5s
kW
G
Product Product Rated Output Output Type of No. of HP & Speed H x W x D Net Weight
Name Number Current /Voltage/Duty Cycle Range Engine Cyl. (rpm) inches (mm) lbs.(kg)
Power Arc ® 5500 Subaru Robin ® K1429-12 125A/20V/30% 70-125A AC Subaru Robin ® 1 9 @ 3600 21 x 20 x 30 160 (72.5)
100A/25V/60% 5,500 Watts Surge EX 27 Gasoline (530 x 508 x 762)
Power Arc ® 5500 Honda ® K1429-13 4,000 Watts Honda ® 169 (76.6)
Continuous GX 270 Gasoline
Product Product Rated Output Output Type of HP & Speed H x W x D Net Weight
Name Number Current /Voltage/Duty Cycle Range Engine No. of Cyl. (rpm) inches (mm) lbs.(kg)
Weldanpower ® 125 K1444-4 125A DC/25V/30% 50-125A DC Subaru Robin ® 1 9 @ 3600 21 x 20 x 30 180
100A DC/25V/60% 5,500 Watts Surge EX 27 OHC (530 x 508 x 762) (82)
4,250 Watts Gasoline
Continuous
DC CC 5.5s
kW
G
• 125 amps DC welding output gives you access
to steel, stainless steel, cast iron or hardfacing
projects.
• Plenty of 120 or 240 volt AC generator power
5500 watts surge (4250 watts continuous) for
lights, tools, pumps, or emergency power
outage needs.
• Rugged tubular roll cage provides added pro-
tection and a host of handy lift handle points.
• The chain-driven OHC (Overhead Cam)
Subaru Robin ® 9 HP EX 27 engine is easy to
start, delivers low noise and good fuel economy.
• Three-year warranty on welder. (Engine is
warranted separately by the manufacturer.)
Contractors and maintenance teams will appreciate the great arc and robust welding of the
Weldanpower
® 125. Step up to a DC welding machine to run smooth DC stick electrodes for
welding projects on steel, stainless steel, cast iron or hardfacing. The handyman, farmer and
small contractor will also value the 5500 watt AC generator power for lights, tools, pumps
and emergency power.
Processes
• Stick
Output Input
Key Options
• K875 Accessory Kit, 150 Amp
• K882-2 Hand Moving
Undercarriage (2 wheels)
Literature
E6.21
Engine Drives: Commercial/Small Contractors
