Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Current /Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power Wave ® i400 K2669-1 200/230/380-415/460/575/3/50/60 50/60Hz: 50/60Hz: 5-420A 21 x 18.5 x 23.6 209
350A/34V/100% 350A/34V/100% 10-37V (533 x 470 x 600) (95)
400A/36V/60% 400A/36V/60%
420A/37V/40% 420A/37V/40%
Automated Solutions
www.lincolnelectric.com/automated-solutions 93
Power Wave
®
i400
The Power Wave ® i400 & AutoDrive ™ 4R90 (see below) solution delivers Lincoln’s best performance
technologies and welding processes all rolled into one highly efficient inverter power source
paired with a compact, durable wire feeder designed for high-end robotic welding.
Intelligent Robotic Solution
AutoDrive
™
4R90
Industry Leading Design
Processes
• CV-MIG
• Pulsed MIG
• Flux-Cored
• Metal-Cored
Output Input
Unit Includes
• Outguide
• Incoming Bushing/Conduit
Connector
Key Options
• K1505-035S Four-Roll Drive
& Split Wire Guide Kit
(Solid Steel Wire)
• K1505-045S Four-Roll Drive
& Split Wire Guide Kit
(Solid Steel Wire)
• More options at end of section
Literature
E4.20
Processes
• CV-MIG
• Pulsed-MIG
• Flux-Cored
• Metal-Cored
• Stainless
• Aliminum
Output Input
Key Options
• K1785-25 14-14 Con trol Cable
• K2670-1 CE Filter Kit
• K2677-1 Integration Kit
• K1543-25 ArkLink
® Control Cable
• More options at end of section
Wire Feeders
• K2685-2 AutoDrive
™ 4R90
• K1780-2 Power Feed ™ 10R
Literature
E4.20
CV DC
40
VDC
3
PHASE
60
50
Hz
Shown:
Power Wave ® i400 Power Source
• Integrated Design – Designed to “nest” in the upper arm of the
FANUC ® Robotics 100iC arm.
• Durable and Rugged – Patented MAXTRAC ® wire drive is precision
cast aluminum designed to provide reliable feed force.
• Ease of Use – Unlike competitive models, no tools are required
for drive roll, wire guide or pressure arm adjustment.
• High Performance – Brass-to-brass gun connections
provide more reliable electrical connectivity and
more efficient energy transfer.
• Best in Class Torque – Results in faster acceleration
and reliably pulls wire through conduit.
• Precise Control – Dual spring pressure arms offer
clear-cut adjustment for optimizing pressure for
different wire types.
• Welding Results – High resolution tachometer
for accurate wire feed speed control.
• Optimized Robotic Solution – Compact, lighter
weight packaging maximizes robot acceleration
performance and through put.
• Flexible Design – Designed for simple, seamless integration
with the FANUC ® Robotics R-30iA Controller, or use as a sep-
arated configuration to meet your weld cell requirements.
• Quality and Consistent Welding Results – Lincoln’s
Waveform Control Technology ® gives you the ability
to select the right waveform for each application.
• High Performance Digital Communications – High
speed digital communication via ArcLink ® protocol, a
CAN connection or now the ArcLink XT ™ , the ArcLink ®
protocol can be communicated over an Ethernet cable.
• Best in Class Power – 5-420 amps output delivers
the power you need for a wide range of processes
and materials, with no derating for pulse waveforms.
• Industry Leading Technology – New high speed digital
controls lead the industry in the performance of this
welding package.
• Ready to Perform – Auxiliary outlet offers flexibility to
add fume extraction, water cooler, computer or other
accessories quickly and easily.
Product Product Wire Feed Speed Range Wire Size Range – Solid Wire Size Range – Cored H x W x D Net Weight
Name Number in/min (m/min) inches (mm) inches (mm) inches (mm) lbs.(kg)
AutoDrive ™ 4R90 K2685-2 30-800 .025-.045 .035-.045 9.1 x 7.5x 8.4 13.5
(0.8-20.3) (0.6-1.2) (0.9-1.2) (231 x 141 x 213) (6.1)
Shown:
AutoDrive ™ 4R90
