Power MIG ® 140C
Premium 120 Volt Input Wire Welder
Power MIG ® 180C
Premium 230 Volt Compact Wire Welder
Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Voltage/Phase/Hertz Current /Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power MIG ® 140C K2471-1 120/1/60 90A/19.5V/20% 20A 30-140 Amps DC 14 x 10.15 x 18.6 58
(Continuous Voltage Control) 50-500 ipm WFS (357 x 258 x 472) (26.3)
(1.3-12.7 m/min)
Max. OCV: 33V
DC 1
PHASE
60
Hz
CV
Home projects and repair, sheet metal and autobody work, farm and small shop welding—the
Power MIG
® 140C designed for 120 volt household power does it all!
• Exclusive Diamond Core ™ Technology delivers
an outstanding arc you’ll notice immediately:
– Great arc starts make getting started easy.
– Wide voltage “sweet spot” gives you a very
forgiving arc.
– Extremely low spatter reduces clean-up.
– Outstanding aluminum & stainless
performance.
• Wide 30-140 amp welding output range is
the highest output in the 120 volt input
power welder class.
• MIG weld 24 gauge up to 10 gauge (.135")
sheet metal in a single pass. Weld up to
5/16” steel using self-shielded Lincoln
Innershield
® wires (FCAW-S).
• Three-year warranty on parts and labor.
• Exclusive Diamond Core ™ Technology delivers
an outstanding arc you‘ll notice immediately:
– Great arc starts make getting started easy.
– Wide voltage “sweet spot” gives you a very
forgiving arc.
– Extremely low spatter reduces clean-up.
– Outstanding aluminum & stainless
performance.
• Wide 30-180 amp welding output
range is the highest output in this
welder class.
• MIG weld 24 gauge up to 3/16" sheet
metal in a single pass. Weld up to 1/2"
steel using self-shielded Lincoln
Innershield
® wires (FCAW-S).
• Three-year warranty on parts and labor.
Whether you’re a farmer or a fabricator, an autobody shop or a backyard mechanic, the Power
MIG
® 180C helps you get the job done! It’s a portable wire welder designed for use with industrial
230 volt input power, so you can weld on thicker material—up to 3/16"
with MIG welding and 1/2" with gas-less flux-cored welding.
Shown:
K2471-1 Power MIG ® 140C
Shown:
K2473-1 Power MIG ® 180C
Processes
• MIG
• Flux-Cored
Output Input
Unit Includes
• Magnum
® 100L Gun, 10 ft. (3.0 m)
• Gas and Gasless Nozzles
• Cable Liner
• Contact Tips
• Work Cable and Clamp
• Adjustable Gas Regulator & Hose
• Spindle Adapter
• 2 lb. (0.90 kg) Spool of SuperArc
®
L-56 Mild Steel MIG Wire
• 1 lb. (0.45 kg) Spool NR ® -211-MP
Flux-Cored Wire
• Learn-To-Use DVD
Key Options
• K520 Utility Cart, 150 cu ft. bottle
capacity
• K2377-1 Small Canvas Cover
• K2525-1 Spot Timer Kit
• K2532-1 Magnum
® 100SG
Spool Gun
• More options at end of section
Literature
E7.23
Processes
• MIG
• Flux-Cored
Output Input
Unit Includes
• Magnum
® 100L Gun, 10 ft. (3.0 m)
• Gas and Gasless Nozzles
• Cable Liner
• Contact Tips
• Work Cable and Clamp
• Adjustable Gas Regulator & Hose
• Spindle Adapter
• 2 lb. (0.90 kg) Spool of SuperArc
®
L-56 Mild Steel MIG Wire
• 1 lb. (0.45 kg) Spool NR ® -211-MP
Flux-Cored Wire
• Learn-To-Use DVD
Key Options
• K520 Utility Cart, 150 cu ft. bottle
capacity
• K2377-1 Small Canvas Cover
• K2525-1 Spot Timer Kit
• K2532-1 Magnum
® 100SG
Spool Gun
• More options at end of section
Literature
E7.24
DC 1
PHASE
60
Hz
CV
Product Product Input Power Rated Output Input Current @ H x W x D Net Weight
Name Number Voltage/Phase/Hertz Current /Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power MIG ® 180C K2473-1 208/230/1/60 130A/17V/30% 20A 30-180 Amps DC 14 x 10.15 x 18.6 66
(Continuous Voltage Control) 130A/17V/30% 50-500 ipm WFS (357 x 258 x 472) (30)
(1.3-12.7 m/min)
Max. OCV: 33V
www.lincolnelectric.com/mig-welders
MIG: Wire Feeder/Welders
