The Ranger ® 3 Phase is an excellent choice for powering crop irrigation circle pumps.
Ranger
®
3 Phase
480V 3-Phase Portable Power for the Farm, Ranch or Job Site
• 480V 3-Phase AC generator power for irrigation
circles or farm pumps.
• 10,500 watts peak single-phase power to start
single-phase motors.
• Smooth AC/DC welding output for a broad range
of Fleetweld ® and Excalibur ® stick electrodes.
• Arc Gouge with up to 5/32" (4.0 mm) carbon
electrode.
• Three-year warranty on welder. (Engine is
warranted separately by the manufacturer.)
Product Product Rated Output Output Type of HP & Speed H x W x D Net Weight
Name Number Current /Voltage/Duty Cycle Range Engine No. of Cyl. (rpm) inches (mm) lbs.(kg)
Ranger ® 3 Phase K2337-2 225A AC CC/25V/100% 50-225A AC 50-210A DC Kohler OHV Command ® 2 23 @ 3600 30.3 x 19.1 x 42.3 538
210A DC CC/25V/100% 15-25V CV CH23S (770 x 485 x 1074) (244)
200A DC CV/20V/100% 1-Phase: 10,500 watts peak
9,500 watts continuous
3-Phase: 11,500 watts peak
10,500 watts continuous
Processes
• Stick
• TIG
• MIG
• Flux-Cored
• Gouging
Output Input
Key Options
• K866-1 Canvas Cover
• K2635-1 Small 2-Wheel Road
Trailer w/Combination Ball/Eye
Hitch
• K704 Accessory Kit, 400 Amp
•
More options at end of section
Literature
E6.94
AC
DC CV
CC
kW
5 . 11 P G
Select the Ranger ® 3 Phase for portable auxiliary power on the farm,
ranch or construction sites. This rugged Ranger ® delivers up to 11,500
watts peak three phase 480V power for farm irrigation circles, pumps
and other power-hungry applications, or 10,500 watts peak single
phase power for lights, grinders and farm, shop or home
auxiliary power. You can also use the Ranger
® 3 Phase
for AC/DC stick welding and arc gouging, as well as
TIG, MIG and flux-cored welding.
www.lincolnelectric.com/engine-drives
Engine Drives: Commercial/Small Contractors
