Environmental Systems Options
See “Recommended General Options” pgs. 149-171 for descriptions.
Miniflex ™
Expendable Parts
KP2390-1 LongLife ® -H Filter
KP2390-2 HEPA Filter
KP2390-3 Miniflex ™ Prefilter
General Options
K2389-5 EN 20 Nozzle
K2389-6 EN 40 Nozzle
K639-1 SHM-300 Suction Head for Manual Welding, 12"
K639-2 SHM-400 Suction Head for Manual Welding, 16"
K639-3 SHM-500 Suction Head for Manual Welding, 20"
K639-4 SHMS Low Noise Suction Nozzle
K639-5 SHFA Flat Suction Head with Flexible Arm
K639-6 UNM Suction Head for Heavy Smoke
K639-14 SHMT Round Suction Head with Flexible Arm
K2389-3 NKT Nozzle Kit, 1" x 8' Hose, 1-3/4" Hose Adapter
K2389-4 NKC Nozzle Kit, 1" x 8' Hose, 1-3/4" Hose Adapter
K2389-8 Extraction Hose, 1-3/4 " x 16'
K2389-9 Extraction Hose, 1-3/4" x 8'
K2389-10 Hose-to-Hose Adapter, 1-3/4" x 1-3/4""
K2389-2 Hose Connection Outlet
K2389-1 Activated Carbon Filter
K2389-7 MBH Wall Mounting Bracket
Mobiflex ™ 200-M
Hose/Hood Set or Extraction Arm
K1668-1
Hose and Hood Set (requires S23267 Flange Adapter)
K2633-1 LFA 3.1 10 ft. Extraction Arm
K2633-2 LFA 3.1 10 ft. Extraction Arm with Lamp/Arc Sensor
K2633-3 LFA 4.1 13 ft. Extraction Arm
K2633-4 LFA 4.1 13 ft. Extraction Arm with Lamp/Arc Sensor
General Options
K1706-2 Work Lamp with Arc Sensor
K1494-3 Starter Overload Switch for 230V
K1673-1 LongLife ® Filter (for 200-M)
K1852-1 Activated Carbon Filter
Mobiflex ™ 400-MS
Hose/Hood Set or Extraction Arm
K1668-1 Hose and Hood Set (requires S23267 Flange Adapter)
K2633-1 LFA 3.1 10 ft. Extraction Arm
K2633-2 LFA 3.1 10 ft. Extraction Arm with Lamp/Arc Sensor
K2633-3 LFA 4.1 13 ft Extraction Arm
K2633-4 LFA 4.1 13 ft Extraction Arm with Lamp/Arc Sensor
General Options
K1706-2 Work Lamp with Arc Sensor
K1494-3 Starter Overload Switch for 230V
K1673-2 LongLife ® Filter (for 400-MS)
Statiflex ™ 200-M Single and Dual Arm
Wall Mounted Filtration Units
K1654-1 Statiflex 200-M Single Arm Base Unit
(includes disposable filter, mounting bracket and
one hose kit - 1m length)
K1654-2 Statiflex 200-M Dual Arm Base Unit
(includes disposable filter, mounting bracket and
two hose kits - 1m length each)
TO CREATE A SINGLE ARM PACKAGE, CHOOSE ONE ITEM FROM
CATEGORY 2, AND ONE ITEM EACH FROM SYSTEMS 3A OR 3B
TO CREATE A DUAL ARM PACKAGE, CHOOSE TWO ITEMS FROM
CATEGORY 2, AND TWO ITEMS EACH FROM SYSTEMS 3A OR 3B
Extraction Arms (Category 2)
K1655-3 LTA 2.0 Telescopic Extraction Arm
K1655-5 LFA 2.0 6.5 ft Extraction Arm
K1655-1 LFA 3.1 10 ft Extraction Arm
K1655-2 LFA 4.1 13 ft Extraction Arm
K1655-6 LFA 4.1-LC Low Ceiling 13 ft Extraction Arm
Standard System (Category 3A) – requires fan, starting control and
mounting brackets
K1656-1 SF 2400 Stationary Fan (1 HP)
K1494-2 Starter Overload Switch for 115V
K1494-3 Starter Overload Switch for 230V
K1669-4 Lamp Kit with Arc Sensor for Wall Mounted Arms
K1657-1 SF 2400 Wall Mounting Bracket
K1657-2 SF 2400 Wall Mounting Bracket
Extension Crane System (Category 3B) – requires fan, starting control
and extension crane
K1656-4 SF 4200 Stationary Fan (2 HP)
K1494-10 Starter/Overload Switch for SF4200 Fan
K1669-10 Lamp with Arc Sensor for SF4200 Fan
K1671-1 EC 2 (7 ft) Extension Crane
K1671-2 EC 4 (14 ft) Extension Crane
K1672-1 Feeder Hanging Rail
General Options
K1750-1 230V Conversion Kit for SF 2400 Fan
K1673-1 LongLife Filter (for 200-M)
K1852-1 Activated Carbon Filter
K1534-2 Air Exhaust Silencer
K1743-2 Non-Return Valve
Statiflex ™ 400-Ms Single Arm
Wall Mounted Filtration Unit
K1742-1 Statiflex 400-MS Base Unit
(includes disposable filter, mounting bracket and
one hose kit - 1m length)
TO CREATE A SINGLE ARM PACKAGE, CHOOSE ONE ITEM FROM
CATEGORY 2, AND ONE ITEM EACH FROM SYSTEMS 3A OR 3B
Extraction Arms (Category 2)
K1655-3 LTA 2.0 Telescopic Extraction Arm
K1655-5 LFA 2.0 6.5 ft Extraction Arm
K1655-1 LFA 3.1 10 ft Extraction Arm
K1655-2 LFA 4.1 13 ft Extraction Arm
K1655-6 LFA 4.1-LC Low Ceiling 13 ft Extraction Arm
Standard System (Category 3A) – requires fan, starting control and
mounting brackets
K1656-1 SF 2400 Stationary Fan (1 HP)
K1669-4 Lamp Kit with Arc Sensor for Wall Mounted Arms
K1657-1 SF 2400 Wall Mounting Bracket
K1657-2 SF 2400 Wall Mounting Bracket
Extension Crane System (Category 3B) – requires fan, starting control
and extension crane
K1656-4 SF 4200 Stationary Fan (2 HP)
K1669-10 Lamp with Arc Sensor for SF4200 Fan
K1671-1 EC 2 (7 ft) Extension Crane
K1671-2 EC 4 (14 ft) Extension Crane
K1672-1 Feeder Hanging Rail
General Options
K1750-1 230V Conversion Kit for SF 2400 Fan
K1673-2 LongLife Filter (for 400-MS)
K1534-2 Air Exhaust Silencer
K1743-2 Non-Return Valve
( See pages 164 and 169 for Fume Extraction Guns )
