Power Wave
®
AC/DC 1000 ™
The Power Wave ® AC/DC 1000 ™ is the first power
source to introduce Waveform Control Technology ®
to submerged arc welding. An operator can increase
weld speeds, yield higher quality welds and improve
efficiencies in a single or multi-arc environment.
Increase Productivity, Quality and Flexibility
• Eliminate downtime with easy polarity switching—
no hardware reconfiguration required.
• Stable and independent arc controls for multiple arc
applications.
• Improved efficiency and reliability with cooler operation
through patented Coaxial Transformer Technology ® .
• 95% power factor correction enables connection of
more machines on the same plant infrastructure for
lower installation costs compared to other machines.
• Remote process monitoring and control through
ArcLink ® , Ethernet, and DeviceNet ™ communication.
• Consistent operation over ± 10% input voltage variation
through built-in line voltage compensation and reliable
input voltage connection.
• Three-year warranty on parts and labor.
Processes
• Submerged Arc
Output Input
Key Options
• K2362-1 Power Feed
™ 10A
• K2282-1 System Interface
• K1543-8 ArcLink
® /Linc-Net
Control Cable, 8 ft
• K1785-12 Control Cable (Heavy
Duty), 12 ft.
• More options at end of section
Wire Feeders
Power Feed
™ 10SF,
Power Feed ™ 10S,
Power Feed ™ 10SM
Literature
E10.96
AC
DC
3
PHASE
60
50
Hz
CV
CC
Product Product Rated Output Input Current @ H x W x D Net Weight
Name Number Input Power Current /Voltage/Duty Cycle Rated Output Output Range inches (mm) lbs.(kg)
Power Wave ® K2344-2 (1) 380/400/460/500/ 1000A/44V/100% 82/79/69/62/55A 100-1000A 43.5 x 19.2 x 33 650
AC/DC 1000 575/3/50/60 (1105 x 488 x 838) (295)
(1) External filter is required to meet CE conducted emission requirements. The K2444-1 must be used with the K2344-2.
• New Product Software Releases
• System Upgrades
• Weld Sets
• Personal Computer &
Diagnostic Tools
Advanced Process Welders
www.lincolnelectric.com/multi-process-welders 39
