Ranger
®
250
For contractors, construction and maintenance applications, this tough Lincoln ® gasoline-driven
welder/generator delivers 250 amps for welding at 100% duty cycle. You can weld with stick,
Touch Start TIG
® DC, flux-cored wire, MIG wire and arc gouge.
250 Amp DC Gasoline Engine-Driven Welder/Generator
Ranger
®
250 LPG
250 Amp DC Liquid Propane Gas Engine-Driven Welder/Generator
Processes
• Stick
• TIG
• MIG
• Flux-Cored
• Gouging
Output Input
Key Options
• K886-2 Canvas Cover
• K2635-1 Small Two-Wheel Road
Trailer with Duo-Hitch ™ : Ball/Eye
Hitch Combo
• K704 Accessory Kit, 400 Amp
• K857-1 Remote Output Control,
100 ft. (30 m)
• More options at end of section
Literature
E6.103
DC
CV
CC
kW
5 . 10 P G
Processes
• Stick
• TIG
• MIG
• Flux-Cored
• Gouging
Output Input
One-Pak ® Package Includes
• K2336-2 Ranger ® 250 LPG
• Factory Undercarriage
• Welding Gas Cylinder/LPG Tank
Holder
• LPG Tank Strap
• K704 Accessory Kit, 400 Amp
• Six 10 lb. cans 1/8" dia. Excalibur
®
7018 Stick Electrode
Key Options
• K886-2 Canvas Cover
• K704 Accessory Kit, 400 Amp
• K857-1 Remote Output Control,
100 ft. (30 m)
• More options at end of section
Literature
E6.104
• Lincoln’s ® Chopper Technology ® provides easy starts, a
smooth arc, low spatter and excellent bead appearance.
• Arc Force control provides a soft or more forceful
digging arc.
• Built-in “hot” start for easier starts and restrikes.
• Touch Start TIG ® DC—Simply lift tungsten to start
the arc.
• Arc gouging with up to 3/16" (4.8 mm) carbons.
• A portable powerhouse—Delivers 10,000 watts
peak (9,000 watts continuous) watts of 120V/240V
AC generator power.
• Fully enclosed case for equipment protection
and low noise.
• Three-year warranty on welder. (Engine is warranted
separately by the manufacturer.)
DC
CV
CC 10
kW
P
L
P
G
Product Product Rated Output Output Type of No. of HP & Speed H x W x D Net Weight
Name Number Current /Voltage/Duty Cycle Range Engine Cyl. (rpm) inches (mm) lbs.(kg)
Ranger ® 250 K1725-12 250A DC CC/28V/100% 20-250A DC Subaru Robin ® OHV EH65 Gas 2 22 @ 3600 36.2 x 21.5 x 42.3 518
250A DC CV/28V/100% 40-250A Pipe (Vacuum Fuel Pump) (920 x 546 x 1074) (235)
K1725-10 275A DC CV/27V/60% 20-250A DC TIG Kohler ® OHV Command ® CH23S Gas 23 @ 3600 500
14-28V CV (Mechanical Fuel Pump) 227
K1725-11 10,500 watts peak Kohler ® OHV Command ® CH23S Gas
9,500 watts continuous (Electric Fuel Pump)
• Lincoln’s ® Chopper Technology ® provides easy starts, a
smooth arc, low spatter and excellent bead appearance.
• Arc Force control provides a soft or more forceful
digging arc.
• Built-in “hot” start for easier starts and restrikes.
• Touch Start TIG ® DC—Simply lift tungsten to start the arc.
• Arc gouging with up to 3/16" (4.8 mm) carbons.
• A portable powerhouse—Delivers 10,500 watts peak (9,500
watts continuous) of 120V/240V AC generator power.
• Fully enclosed case for equipment protection and low noise.
• Three-year warranty on welder. (Engine is warranted
separately by the manufacturer.
Product Rated Output Type of No. of HP & Speed H x W x D Net Weight
Name Current /Voltage/Duty Cycle Output Range Engine Cyl. (rpm) inches (mm) lbs.(kg)
Ranger ® 250 LPG K2336-2 250A DC CC/28V/100% 20-250A DC Kohler ® OHV Command ® 2 25 @ 3600 36.2 x 21.5 x 42.3 482
250A DC CV/28V/100% 40-250A Pipe CH730 LPG (920 x 546 x 1074) (218)
275A DC CV/27V/60% 20-250A DC TIG
Ranger ® 250 LPG K2371-2 14-28V CV — —
One-Pak ® Package 10,000 watts peak — —
9,000 watts continuous
For environments where gasoline and diesel emissions are unacceptable, this tough
Lincoln
® LPG fuel welder/generator delivers 250 amps for welding at 100% duty cycle.
It’s recommended for stick welding as well as Touch Start TIG ® DC, flux-cored wire,
MIG wire and arc gouging.
www.lincolnelectric.com/engine-drives
Engine Drives: Commercial/Small Contractors
49
