310
syngo Dynamic Evaluation
• Baseline image segment
The baseline image is displayed in the lower left
hand segment (base for enhancement calculation).
By default, the first image of the loaded images is
used as the baseline image.
• Result segment
It is black after loading.
2. Inspecting the Input Images
Before you begin the evaluation, optimize the display
of loaded images in the tomo segment in such away
that the regions to be evaluated are clearly visible:
– Scroll through the image stack
– Window, zoom and pan images
– Remove the images that are not suitable for dynamic
evaluation (e.g., when the patient has moved during
scanning).
3. Generation of Parameter Images
As soon as you load the original image material, your
system performs an evaluation of the entire image
area. The results (parameter images) are displayed in
the parameter image segment.
