177
Working with SD “24P” material
486p @ 23.98 fps workflow example
The following diagram illustrates a typical 486p @ 23.98 fps workflow using
Matrox RT.X2:
¦ Note For all Matrox RT.X2 projects, you can choose to export to an MPEG-2
file for DVD authoring or export to a web format using Matrox Media Encoder as
explained in
“Exporting using Matrox Media Encoder” on page 43 . For details on
other export formats, see “Exporting to a Matrox .avi file” on page 36 . When
working with an SD project on RT.X2, you can also capture video directly to an
.m2v file for DVD authoring using Adobe Encore.
DV camera performs either standard or
advanced pulldown (depending on mode
selection) when the acquired footage is
recorded to tape or disk.
Exported to DV tape as
NTSC video
Exported to disk as MPEG-2
IBP for DVD authoring or
exported to disk to streaming
video format for web
Matrox RT.X2
using a
486p @ 23.98 fps
project preset
Depending on the user’s selection of
pulldown method, Matrox RT.X2 performs
either advanced 2:3:3:2 pulldown or
standard 2:3 pulldown.
DV-1394 input/output, and
P2 .mxf source files on disk
Matrox RT.X2 detects original pulldown
method, then performs either an advanced
or standard reverse pulldown during
capture (or playback for .mxf files).
SD video footage acquired
at 23.98 fps progressive
scan
NTSC video on tape or
P2 .mxf files on disk
