Advance Information MC68HC(7)08KH12 — Rev. 1.1
148 Freescale Semiconductor
9.5.9 USB Embedded Device Endpoint 1/2 Data Registers (DE1D0-DE1D7)
DE1TD7-DE1TD0 — Embedded Device Endpoint 1/ Endpoint 2
Transmit Data Buffer
These write only buffers are loaded by software with data to be sent
on the USB bus on the next IN token directed at Endpoint 1 or
Endpoint 2 of the embedded device. These buffers are shared by
embedded device Endpoints 1 and 2 and depend on proper
configuration of the ENDADD bit.
Address: $0028
Bit 7 6 5 4 3 2 1 Bit 0
Read:
Write: DE1T07 DE1T06 DE1T05 DE1T04 DE1T03 DE1T02 DE1T01 DE1T00
Reset: X X X X X X X X
↓ ↓
Address: $002F
Read:
Write: DE1T77 DE1T76 DE1T75 DE1T74 DE1T73 DE1T72 DE1T71 DE1T70
Reset: X X X X X X X X
= Unimplemented X = Indeterminate
Figure 9-20. USB Embedded Device Endpoint 0 Data Register
(UE0D0-UE0D7)
