LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
94
8.12. Physical register #11, 12, 13 (read)
Physical Register#11, 12, 13 are the registers that indicate Vendor_ID of this node.
phy/
link-
addr
R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
20 h R - - - - - - - - Vendor_ID-hi
Fixed Value ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ “00 h”
22 h R - - - - - - - - Vendor_ID-mid
Fixed Value ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ “00 h”
24 h R - - - - - - - - Vendor_ID-lo
Fixed Value ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ “0E h”
Description of Each Bit
BIT Bit Name Action Value Function
15 - 8 reserved Read - Always indicate ‘0’.
7 - 0 Vendor_ID Read -
Indicate Vendor ID of Fujitsu (MSB: 7, LSB: 0).
Always indicate fixed value “00000E h”.
