LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
21
WRITE READ
Address
(HEX)
Register Name Register Name
50 (reserved) data bridge transmit/receive status [B]
52 (reserved) Isochronous channel monitor 1
54 (reserved) Isochronous channel monitor 2
56 (reserved) Isochronous channel monitor 3
58 (reserved) Isochronous channel monitor 4
5A (reserved) cycle-time-monitor (upper)
5C (reserved) cycle-time-monitor (lower)
5E (reserved) Ping time monitor
60 PHY/LINK register address setting PHY/LINK register address setting
62 PHY/LINK register access port PHY/LINK register access port
64 (reserved) Revision indicate register (upper)
66 (reserved) Revision indicate register (lower)
68 (reserved) (reserved)
6A (reserved) (reserved)
6C (reserved) (reserved)
6E (reserved) (reserved)
70 (reserved) (reserved)
72 (reserved) (reserved)
74 (reserved) (reserved)
76 (reserved) (reserved)
78 (reserved) (reserved)
7A (reserved) (reserved)
7C (reserved) (reserved)
7E (reserved) (reserved)
