8.15. Link register #00 (read/write)

Link Register#00 is the register that sets this node to operate as cycle master.

phy/
link-

addr

R/W

Bit

15

Bit

14

Bit

13

Bit

12

Bit

11

Bit

10

Bit

9

Bit

8

Bit

7

Bit

6

Bit

5

Bit

4

Bit

3

Bit

2

Bit

1

Bit

0

3C h

R/W

-

-

-

-

-

-

-

-

-

-

cycle

master

-

-

-

-

-

Initial Value

‘0’

‘0’

‘0’

‘0’

‘0’

‘0’

‘0’

‘0’

‘0’’

‘0’

‘1’

‘0’

‘0’

‘0’

‘0’

‘0’

<

< Description of Each Bit

BIT

Bit Name

Action

Value

Function

Read

-

Always indicate ‘0’.

15 - 6

reserved

Write

-

Always write in ‘0’.

0

Does not cycle master.

Read

1

Operates as cycle master if it is root.

5

cycle master

Write

-

Sets the value of this bit at ‘1’ by writing in ‘1’.

Read

-

Always indicate ‘0’.

4 - 0

reserved

Write

-

Always write in ‘0’.
