LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
41
7.11. TSP Receive Information Setting Register
T SP receive information setting register performs the setting for outputting received packet to TSP -IC
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
1Ch R/W TV2B TV1B - -
output
DSS
size-B
DV-
EN
DSS-
EN
TS-E
N
TV2A TV1A - -
output
DSS
size-A
TCL
KSL
CMP
SEL
TSC
MP
Initial Value ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘1’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’ ‘0’
BIT Bit Name Action Value Function
0 Does not output packet received by bridge -Bch to port B of TSP -IC I/F.
15 TV2B
Read/
Write
1 Outputs packet received by bridge-Bch to port B of TSP -IC I/F.
0 Does not output packet received by bridge -Bch to port A of TSP -IC I/F.
14 TV1B
Read/
Write
1 Outputs packet received by bridge-Bch to port A of TSP-IC I/F.
Read - Always indicates ‘0’.
13 - 12 reserved
Write - Always write in ‘0’.
0
Outputs DSS packet received by bridge -Bch, with DSS packet header attached, to
TSP -IC in unit of 140 byte.
11
output DSS
size-B
Read/
Write
1
Outputs DSS packet received by bridge- Bch, without attachment of DSS packet
header, to TSP-IC in unit of 130 byte.
Removed DSS packet header is stored at receive DSS packet header indicate
register [B].
0
Deletes received data and reports FMT error when DV data is received.
ISO packet header and CIP header are indicated in register.
10 DV-EN
Read/
Write
1 Allows receiving DV data.
0
Deletes received data and reports FMT error when DSS data is received.
ISO packet header and CIP header are indicated in register.
9 DSS-EN
Read/
Write
1 Allows receiving DSS data.
