LSI S pecification MB86617A
Rev.1.0 Fujitsu VLSI
50
7.17. Data Bridge Transmit Information Setting Register 3 [B]
Data bridge transmit information setting register 3 [B] is the register that sets CIP header range added to transmit packet processed by
bridge-Bch.
AD R/W
Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
38h R/W Tx SID-B Tx DBS-B Tx FN-B
Initial Value “00 h” “00 h” “00 b”
BIT Bit Name Action Value Function
15 - 10 Tx SID-B
Read/
Write
-
Write in SID range of transmit CIP header.
(MSB: bit15, LSB: bit10)
9 - 2 Tx DBS-B
Read/
Write
-
Write in DBS range of transmit CIP header.
(MSB: bit9, LSB: bit2)
MPEG2-TS at transmit: “00000110 ” b
DSS at transmit: “00001001 ” b
1 - 0 Tx FN-B
Read/
Write
-
Write in FN range of transmit CIP header.
(MSB: bit1, LSB: bit0)
MPEG2-TS at transmit: “11” b
DSS at transmit: “10” b
